P. 455

                    HEATING & VENTILATION Ventilation
Monsoon Energysaver - Zone 1 Silence Fan Range
The new Monsoon Silence range is the latest innovative domestic ventilation solution, providing high extraction rates with low energy use and exceptionally quiet running levels. The fan comes with a long life ball bearing motor and a silent back draft shutter preventing air travelling back up the duct and into the room.
national ventilation
  • Can be mounted within Zone 1
• Quieter than ever - as low as 22dB(A)
• Window, ceiling or wall mount
• Easier than ever to install with
•
• •
Improved performance –
1m longer duct runs at 15l/s Complies with both Part F & L Now with our longest ever 5 year warranty
Made in the UK
larger terminal block and spirit
level •
Part No. Description
  MONS100TA
  100mm Timer, 2-30 minute, 97m3/h
 MONS100SA
100mm Standard, 97m3/h
 MONS100HTA
 100mm Timer/Humidistat/Pullcord, 97m3/h
 MONS100PCA
  100mm Pull Cord, 97m3/h
 MONS100PIRA
 100mm Passive Infrared c/w Timer 97m3/h
   Monsoon UMD Mixed Flow Fans
The UMD Domestic range can be used for exhaust and supply ventilation systems that require high pressure, powerful airflow and low noise levels.
• High performance and low power consumption
• Motor attached to fan body by two quick release clips for maintenance
• Two speed motor with option of overrun timer (2 to 30 minutes)
• Motor equipped with Standard Thermal
• Overload Protection (STOP), IPX4
• Working temperature of up to 60°,
supply voltage 220-240V 50Hz
• Quick and easy installation
• Made in the UK
100mm Monsoon Shower Extract Kit
Monsoon UMD Pro Mixed Flow Fans
The Monsoon UMD Pro Series is specially designed with an optimised case and an aerodynamic impeller, ensuring the best combination of high air capacity, powerful pressure and low noise level.
• High Extraction Rate - 100mm = 300m3/hr, 150mm = 522m3/hr
• Aerodynamic case and diffuser for powerful pressure at low noise
• High-efficient two speed ball bearing motor, 40,000 hour service life
• Complete with mounting plate, can be mounted at any angle
• Suitable for mounting in parallel or in series
• Quick release impeller and motor block, easy maintenance
• Made in the UK
100mm Monsoon Showerlite LED Extract Kit
     Part No. Description
    UMD100TA 100mm Timer In-line Fan (198m3/h)
  Part No. Description
    UMD100TX 100mm Mixed Flow Timer Fan (300m3/h)
      • High performance and low power consumption - Up to 198m3 /h - As low as 17-19W
• Quick and easy installation
• Made in the UK
• Runs at 28dB(A) on low speed
• Two speed motor with option of
overrun timer (2 to 30 minutes)
GENERATE VALUE
• Motor equipped with Standard Thermal Overload Protection
• IPX4 rated
• Voltage 220-240V 50Hz
• Premium build quality
• Shower grille
• Shower Grille (White and
Chrome) included
• High performance and low power consumption - Up to 198m3 /h - As low as 17-19W
• Quick and easy installation
• Made in the UK
• Runs at 28dB(A) on low speed
• Two speed motor with option of
overrun timer (2 to 30 minutes)
• Motor equipped with Standard Thermal Overload Protection
• IPX4 rated
• Voltage 220-240V 50Hz
• Premium build quality
• Shower Light with Chrome &
White Bezels
Part No. Description
 Part No. Description
    UMDTKLED
  Kit Includes UMD100T, LED Light, 2x Air Diffuser (White and Chrome), 6m PVC Flexible Ducting, External Fixed Grille and 4x Cable Ties
       UMDTK
Kit Includes UMD100T, 2x Internal Diffuser (White and Chrome), 6m PVC Flexible Ducting, External Fixed Grille and 4x Cable Ties
   Together we
455
