P. 457

                    HEATING & VENTILATION
Ventilation
Monsoon EnergysaverTM MON-MEV DC Multi Room Unit
 The Monsoon Energysaver multi-room product is a mechanical extract ventilation unit which has been designed for continuous extract of stale air from separate areas around the home or for commercial applications where a multipoint extractor system is needed, including toilets, changing rooms and cubicles. These multi-room extract units have been developed so they can be installed in many applications and condensate drains are provided where the ambient air has a high humidity content.
 • Suitable for wall, ceiling or loft mounting
• Four 125mm extract points
• Continuous Operation
• Quiet Running
• Extract from numerous rooms • Made in the UK
Part No. Description
  MON-MEVDC-400
 DC Multi Room Unit (425 m3/h – 118 l/s)
 MON-MEVDC/H400
 DC Multi Room Unit built-in Humidistat (425 m3/h – 118 l/s)
 HRU-SPIR
  PIR controller (Not suitable for use with MON-MEV H)
 FT1
 Wired Remote Timer
   Monsoon EnergysaverTM MON-HRU Heat Recovery Range
The Monsoon MON-HRU wholehouse heat recovery range offers up to 90% energy efficiency. The heat recovery cube is easy to access and is protected by two removable G3 filters. The Energy Saving EC/DC fans ensure long life and low energy use. The unit is fully insulated with a built-in condensation drain.
Monsoon EnergysaverTM IntelliSystem Heat Recovery
             • Up to 94% heat recovery efficiency
• Adjustable two speed energy saving, long life EC/DC motors as standard
• Fully controllable with a number of sensors and controllers
GENERATE VALUE
• Frost protection and external condensation drain
• Lightweight and easy access for maintenance
• Touch screen and app control
• Easy installation with
lightweight unit
• Complete summer bypass
• Wi-Fi connectivity
• Wireless commissioning
• USB Pre-commissioning
• Left/right handing
• Pre-heater & post heater options • ISO ePM2.5 & ISO ePM10 filter
options
The Monsoon Energysaver IntelliSystem heat recovery unit from National Ventilation is the latest energysaving heat recovery solution. Simple and effective it has been designed to provide the maximum level of control and comfort available by continuously supplying and extracting air throughout the home ensuring the best possible consumer experience.
Part No. Description
  MON-HRU/230-100
  91% Energy efficient (230m3/h @ 100Pa)
 MON-HRU/330-100
 90% Energy efficient (330m3/h @ 100Pa)
 MON-HRU/400-150
 94% Energy efficient (400m3/h @ 150Pa)
  Part No. Description
  MON-HRU/350-150i
  93% Energy efficient, 350m3/h @ 150pa
 HRU-SPIR
 PIR controller (Not suitable for use with MON-MEV H)
 HRU-HVHT
 Switched Live Humidistat Sensor
     Together we
