                    HEATING & VENTILATION Ventilation
Monsoon Radial Ducting
National Ventilation’s radial air distribution system is designed for use in homes, apartments and small buildings. The radial system is up to 60% quicker and easier to install, saving time and money.
How It Works
The Monsoon Radial Ducting comes on a 50-metre roll, giving you the flexibility to cut it to the correct length for the application. The manifold acts as an air distribution hub, each outlet evenly servicing a different room. Twin or single semi-rigid duct runs are securely connected to a plenum positioned in each room, terminating with an air valve or grille.
    • Corrosion proof with an antistatic and antibacterial coating
• Duct has a smooth inter surface for minimal resistance
• Huge time & cost savings compared to traditional ducting
• Robust, quick and easy to install • Crush resistant and double
walled for flexibility
• Low profile system
• Plug and play system ideal for
self builders
  Part No. Description
  UNRAD75/50
 Radial Ducting Anti-Bacterial 75mm x 50m
 UNVC75/90
 VC70CH 75 Valve Collector 2x Ø75-125 H= 70 90°
 UNB75/90
  BK 90-75 Bend 90° for Flexible Duct Ø75 incl. 2 Gaskets
 UNDB75/12/125
TVG 75 125 Distribution Box 12 x Ø75 Side Connection Spigot Ø125
 UNDB75/8/125
 TVGS 75 125 Distribution Box 8 x Ø75 Side Connection Spigot Ø125
 UNCON75
 KS 75 Coupler + 2 Rubber Gaskets Ø75
 UNSVC75
 Straight Radial Collector 2 x 75, x 125mm
 UNAV125
  Adjustable Valve
 UNQVXL125
Adjustable Valve Large
 UNAVSQ125
  Adjustable Valve Square
 UNAVC125
 Collar
     Monsoon Shuttered Fan Range - 9” & 12” Auto Shutter Fan
230mm fixed grilled fan suitable for panel/wall mounting or window mounting using the appropriate window accessory kit. Suitable for commercial applications in pubs, hotels, restaurants, offices, schools, shops and factories.
 • Simple installation •
• External 2 speed reversible on/
off controller available •
• Manufactured impact resistant high gloss ABS for strength and
Meets the requirements of Building Regulation Document F IP44 rated, DEMKO Approved, and CE marked in accordance with all the relevant EEC Harmonised Directives
 durability
• Motor fitted with thermal over
load protection
• Double Insulated, class II motor fitted with thermal protection
Part No. Description
  MON23A
 225mm Auto Shutter - 190l/s
 MON30A
 300mm Auto Shutter - 267l/s
 MON-WK23
 230mm Window Kit to Suit
 MON-WK30
  300mm Window Kit to Suit
 MON-RS23/30
 2 Speed Reversible On/Off Controller
