467HEATING & VENTILATIONTogether we GENERATE VALUESilent MVUltra Quiet In-Line Duct Fans Ultra quiet and low profile helicocentrifugal in-line fans suitable for a wide range of domestic and commercial applications. Fitted with sound absorbent insulation and manufactured with an adjustable two speed 230V 50Hz motor*. Easy to install and maintain, the SILENT MV fans guarantee exceptional performance with significant noise reduction.*Except for the SILENT MV 160/100, which is fitted with a patented silent axial motor.Part No. Description Max Airflow l/s (m3/h)IP RatingSILMV160/100S Ultra Quiet In-line Fan 50 (180) IP44SILMV160/100T* Ultra Quiet In-line Fan with Adjustable Timer 50 (180) IP44SILMV250/100 Ultra Quiet In-line Fan 69 (250) IP44SILMV250/100T* Ultra Quiet In-line Fan with Adjustable Timer 69 (250) IP44SILMV350/125 Ultra Quiet In-line Fan 96 (330) IP44SILMV350/125T* Ultra Quiet In-line Fan with Adjustable Timer 96 (330) IP44SILMV500/150 Ultra Quiet In-line Fan 153 (550) IP44SILMV500/150T* Ultra Quiet In-line Fan with Adjustable Timer 153 (550) IP44SILMV800/200 Ultra Quiet In-line Fan 253 (910) IP44SILMV800/200T* Ultra Quiet In-line Fan with Adjustable Timer 253 (910) IP44SILMV1000/200 Ultra Quiet In-line Fan 289 (1040) IP44SILMV1000/200T* Ultra Quiet In-line Fan with Adjustable Timer 289 (1040) IP44SILMV1300/250 Ultra Quiet In-line Fan 353 (1320) IP44Loosen the Fixing ClampsOpen Clamps on Both SidesRemove the Fan BodyCarry out the Wiring of the UnitRemove the Terminal Box LidReplace the Body & Tighten ClampsOnce Installed, You’ll Never Know it ExistsIn-Line Duct Fans• Sound absorbent insulation• 360° rotating connection box• Sealed for life ball bearings• Fitted with 2/3 speed motors• Five year guarantee• IP44 rated• Incredibly silent running• High performance• Significant energy savings• Complies with building regulations• Flexible location• Easy maintenanceInnovative EngineeringThe SILENT MV has been designed with state of the art technology to achieve results to satisfy the most demanding specifier. The low profile and compact design of the helicocentrifugal fans enable them to be installed where space is restricted, such as false ceilings.Unique DesignThe unique perforated design of the casing directs sound waves into the high density sound absorbent material to prevent air leakage and minimise noise.Rotating Connection BoxThe connection box can be rotated 360° to enable the power cable to be easily connected.How does it work?Sound waves produced inside the SILENT MV are directed through the perforated inner cover and absorbed by the layer of sound absorbent material.Ease of MaintenanceThe central body of the SILENT MV can be easily dismantled from the connections to enable rapid maintenance, without the need to interfere with the ducting.
