Page 580 - Fegime - Electrical Product Guide Issue 1 V5
P. 580

                    LIGHTING
Photocells, Brackets & Weatherproof Connectors
Photocells
• UV stabilised covers, suitable for use within a luminaire
• Dusk/dawn switching via integrated electronic detector
• 2-year guarantee
brackenheath
Lighting Accessories
Brackets
• Swivel brackets compatible with iSpot Frameless and REX Slim floodlights (up to 50W)
• Steel construction with high quality, durable black finish
• 2-year guarantee
Floodlight Spike
• Fixed floodlight spike compatible with iSpot Frameless and REX Slim floodlights (up to 50W)
• Steel construction with high quality, zinc coated finish
• 2-year guarantee
Scaffold Bracket
• Scaffold bracket compatible with iSpot Frameless and REX Slim floodlights (up to 50W)
• Steel construction • 2-year guarantee
Weatherproof Connector
• Short length, weatherproof connector, compatible with iSpot Frameless, Rex Slim floodlights and LED DualBay ranges
• Easy access terminals for ease of installation
• IP68 rating for total protection against dust and
for continuous immersion in water up to 3m • 2-year guarantee
• BS EN 60598-1
GENERATE VALUE
      Miniature Photocell 500W 16mm
• Miniature photocell for controlling lighting in residential and commercial applications
• 500W (tungsten), 850Va ballast switching capacity, on/off lux level 10-20 Lux on/30-60 Lux off, 230V/50Hz
• Fits within a 16mm knockout
Miniature Photocell Two Part 500W 20mm
• Two-part miniature photocell with a remote head for controlling lighting in residential and commercial applications
• 2x250W max inductive, 250W max fluorescent switching capacity, on/off lux level 70 lux (dusk to dawn), 230V/50Hz
• Fits within a 20mm knockout
Photocell Kit 1000W
• Photocell Kit for controlling lighting in residential and commercial applications
• Supplied with head and base
• 1000W (tungsten), 1800Va ballast switching
capacity, on/off lux level 70 Lux on/105 Lux off, 230V/50Hz
Photocell Kit 400W
• Photocell kit for controlling lighting in residential and commercial applications
• Supplied with head and base
• 400W switching capacity, on/off lux level 70 lux
(dusk to dawn), 230V/50Hz
Miniature Photocell Two Part 100W 16mm
 • Two-part miniature photocell with a remote head for controlling lighting in residential and commercial applications
• 100W (tungsten), 1800Va ballast switching capacity, on/off lux level 10-20 Lux on/30-60 Lux off, 230V/50Hz
Miniature Photocell 500W 20mm
• Miniature photocell for controlling lighting in residential and commercial applications
• 2x250W max inductive, 250W max fluorescent switching capacity, on/off lux level 70 lux (dusk to dawn), 230V/50Hz
• Fits within a 20mm knockout
Photocell Head Only 1000W
• Photocell head for controlling lighting in residential and commercial applications
• Replacement head with NEMA connection
• 1000W (tungsten), 1800Va ballast switching
capacity, on/off lux level 10-20 Lux on/30-60 Lux off, 230V/50Hz
Photocell Head Only 400W
• Photocell head for controlling lighting in residential and commercial applications
• Replacement head with NEMA connection
• 400W switching capacity, on/off lux level 70 lux
(dusk to dawn), 230V/50Hz
Part No. Description
  BTHB2A
  Swivel Corner Bracket
 BTHB3A
 Swivel Wall Bracket
  Part No. Description
 Part No. Description
   N2011 Miniature Photocell 500W 16mm
    N2012 Miniature Photocell Two Part 100W 16mm
   Part No. Description
Part No. Description
   BTHB5A Floodlight Spike
  Part No. Description
   PS41R Miniature Photocell Two Part 500W 20mm
    PS41 Miniature Photocell 500W 20mm
   Part No. Description
   BTHB9A Scaffold Bracket
 Part No. Description
 Part No. Description
   N2013 Photocell Kit 1000W
    N2014 Photocell Head Only 1000W
    Part No. Description
 Part No. Description
Part No. Description
   PS20 Photocell Kit 400W
      PS21 Photocell Head Only 400W
  I4000B Weatherproof Connector Small IP68
 580
