P. 581

                    LIGHTING
LED Panels & Weatherproof Fittings
Commercial Backlit Panels
CCT3 Circular Panels
        Tp(B) Backlit Panels
• LED backlit panel solution for a range of commercial applications
• Slim profile, white aluminium frame with high quality TP(b) diffuser, providing low glare (UGR<21)
• Compatible with Brackenheath’s plug in, self-test emergency pack
• Loop in, loop out terminals provide for an easier and more economical installation
• Suitable for suspended ceilings; surface and
suspension mounting kits available
• IP20 rating, suitable for indoor use
• 5-year guarantee
• BS EN 60598-1
Weatherproof Fittings
• High performance LED weatherproof luminaire providing an energy saving, retrofittable replacement solution for fluorescent fittings used in commercial and industrial applications
• 120Lm/W, 6500K, 120° Beam angle, ENEC approved driver, 220-240V
• Polycarbonate construction with opal diffuser and tamper proof 304 stainless steel mounting clips
• Incorporates a quick fix, two-part, hinged LED tray
• Suitable for surface or suspension mounting, with besa box mounting option and 20mm knockouts
• IP65 rating for total protection against dust and low pressure jets of water from any direction
• 5-year guarantee
• BS EN 60598-1
GENERATE VALUE
Emergency Pack
• Plug-and-play emergency self-test pack for Brackenheath LED panel range
• 3W output power, 12-60V, 2.5Ah Ni-CD/Ni-MH battery with 12V-60V output
• 3 hours emergency duration
• Includes a trailing LED indicator for positioning
alongside panel
• Size: 200x100x33mm • Weight: 800g
• 5-year guarantee
• BS EN 61347-2
Accessories
• 5-year guarantee
• LED backlit panel solution for a range of commercial applications
• Slim profile, white aluminium frame with high quality TP(b) diffuser, providing low glare (UGR<21)
• Compatible with Brackenheath’s plug in, self- test emergency pack
• Loop in, loop out terminals provide for an easier and more economical installation
• Suitable for recessed mounting
• IP20 rating, suitable for indoor use • 3-year guarantee
• BS EN 60598-1
Part No. Description
   BR1191 Panel Remote 3Hr Emergency Pack
 Part No. Description
  BR1214
  120mm 6W CCT3 Circular Panel
 BR1224
150mm 9W CCT3 Circular Panel
 BR1234
  170mm 12W CCT3 Circular Panel
 BR1244
 220mm 18W CCT3 Circular Panel
  Part No. Description
  BR1111
 600x600mm 32W 4000K Panel Tp(B)
 BR1112
  600x600mm 32W 6000K Panel Tp(B)
 BR1121
 1200x600mm 45W 4000K Panel Tp(B)
 BR1122
 1200x600mm 45W 6000K Panel Tp(B)
       Panel Surface Mounting Kit 600x600mm
  IP65 Weatherproof
IP65 Weatherproof with 3 Hour Emergency
Part No. Description
  BR4112
 2FT 27W 6500K IP65 Weatherproof
 BR4114
 4FT 40W 6500K IP65 Weatherproof
 BR4114T
  4FT 55W 6500K IP65 Weatherproof Twin
 BR4115
5FT 40W 6500K IP65 Weatherproof
 BR4115T
 5FT 55W 6500K IP65 Weatherproof Twin
 BR4116
  6FT 60W 6500K IP65 Weatherproof
 BR4116T
 6FT 80W 6500K IP65 Weatherproof Twin
  Part No. Description
  BR4112E
 2FT 27W 6500K IP65 Weatherproof
 BR4114E
 4FT 40W 6500K IP65 Weatherproof
 BR4114TE
  4FT 55W 6500K IP65 Weatherproof Twin
 BR4115E
5FT 40W 6500K IP65 Weatherproof
 BR4115TE
 5FT 55W 6500K IP65 Weatherproof Twin
 BR4116E
  6FT 60W 6500K IP65 Weatherproof
 BR4116TE
 6FT 80W 6500K IP65 Weatherproof Twin
    Together we
581
Part No. Description
 BR1193
  BR1194
Square Panel 6 Wire Suspension Kit
  BR1195
Panel Surface Mounting Kit 600x120mm
