Page 582 - Fegime - Electrical Product Guide Issue 1 V5
P. 582

                    LIGHTING Corn Lamps & Floodlights
Corn Lamps
iSpot Floodlights
• LED iSpot frameless floodlight solution for residential applications
• 90Lm/W, 4000K, 110° beam angle
• High quality black aluminium body with
toughened glass lens and extra long angled mounting bracket allowing the unit to be fully rotational
• Incorporates 220V-240V on-board driver and a condensation release valve for continuous ventilation
• Complete with 0.5m of power flex
• IP65 rating for total protection against dust and
low pressure jets of water from any direction • 3-year guarantee
• BS EN 60598-1
iSpot Frameless Spotlights
      • LED Corn Lamp replacement solution for metal halide lamps, suitable for retrofitting in open high bay and low bay fittings used in a range of commercial and industrial applications, including warehouses and factories
• 140 Lm/W, 6500K, 360° beam angle, lamp life 50,000 hours, IP65, 100-240V
• Aluminium body construction with polycarbonate diffuser, with unique heatsink design eliminating the need for a fan
• Fitting compatible for use with PIR sensors
• 5-year guarantee
• BS EN 60598-1
REX Slim Floodlight
• LED floodlight solution for commercial and industrial applications
• Highqualityblackaluminiumbodywithtoughened glass lens and extra long angled mounting bracket allowing the unit to be fully rotational
• Wide Voltage (100-240V) versions available allowing for installation in multiple applications
• Complete with 0.5m of power flex
• IP65 rating for total protection against dust and
low pressure jets of water from any direction
• 3-year guarantee
• BS EN 60598-1
iSpot Frameless Spotlights with PIR
Part No. Description
  I2013B
 10W 4000K IP65 iSpot Frameless + PIR BK
 I2013W
  10W 4000K IP65 iSpot Frameless + PIR WH
 I2015B
10W CCT3 IP65 iSpot Frameless + PIR BK
 I2023B
 20W 4000K IP65 iSpot Frameless + PIR BK
 I2023W
 20W 4000K IP65 iSpot Frameless + PIR WH
 I2025B
  20W CCT3 IP65 iSpot Frameless + PIR BK
 I2033B
30W 4000K IP65 iSpot Frameless + PIR BK
 I2033W
 30W 4000K IP65 iSpot Frameless + PIR WH
 I2035B
 30W CCT3 IP65 iSpot Frameless + PIR BK
 I2043B
 50W 4000K IP65 iSpot Frameless + PIR BK
 I2043W
  50W 4000K IP65 iSpot Frameless + PIR WH
 I2045B
 50W CCT3 IP65 iSpot Frameless + PIR BK
  Part No. Description
  I2012B
  10W 4000K IP65 iSpot Frameless BK
 I2012W
10W 4000K IP65 iSpot Frameless WH
 I2014B
 10W CCT3 IP65 iSpot Frameless BK
 I2022B
 20W 4000K IP65 iSpot Frameless BK
 I2022W
  20W 4000K IP65 iSpot Frameless WH
 I2024B
20W CCT3 IP65 iSpot Frameless BK
 I2032B
 30W 4000K IP65 iSpot Frameless BK
 I2032W
 30W 4000K IP65 iSpot Frameless WH
 I2034B
 30W CCT3 IP65 iSpot Frameless BK
 I2042B
  50W 4000K IP65 iSpot Frameless BK
 I2042W
 50W 4000K IP65 iSpot Frameless WH
 I2044B
 50W CCT3 IP65 iSpot Frameless BK
  Part No. Description
    R8019
R8036
19W 6500K IP65 Corn Lamp 360˚ E27
  R8027
27W 6500K IP65 Corn Lamp 360˚ E27
  36W 6500K IP65 Corn Lamp 360˚ E40
  R8054
54W 6500K IP65 Corn Lamp 360˚ E40
  R8080
 R8100
80W 6500K IP65 Corn Lamp 360˚ E40
 100W 6500K IP65 Corn Lamp 360˚ E40
       Part No. Description
  N6310
  10W 4000K REX Slim Floodlight
 N6311
10W 4000K REX Slim Floodlight + PIR
 N6320
 20W 4000K REX Slim Floodlight
 N6321
 20W 4000K REX Slim Floodlight + PIR
 N6330
 30W 4000K REX Slim Floodlight
 N6331
  30W 4000K REX Slim Floodlight + PIR
 N6340
50W 4000K REX Slim Floodlight
 N6341
 50W 4000K REX Slim Floodlight + PIR
 N6038
 50W 4000K REX Slim Floodlight 100-240V
 N6045
  70W 4000K REX Slim Floodlight
 N6046
 70W 4000K REX Slim Floodlight + PC
 N6047
 70W 4000K REX Slim Floodlight + PIR
  Part No. Description
  N6048
  70W 4000K REX Slim Floodlight 100-240V
 N6055
100W 4000K REX Slim Floodlight
 N6056
 100W 4000K REX Slim Floodlight + PC
 N6057
 100W 4000K REX Slim Floodlight + PIR
 N6058
 100W 4000K REX Slim Floodlight 100-240V
 N6065
  150W 4000K REX Slim Floodlight
 N6066
150W 4000K REX Slim Floodlight + PC
 N6068
 150W 4000K REX Slim Floodlight 100-240V
 N6075
 200W 4000K REX Slim Floodlight
 N6078
  200W 4000K REX Slim Floodlight 100-240V
 N6085
 300W 4000K REX Slim Floodlight
 N6086
 300W 4000K REX Slim Floodlight + PC
  Part No. Description
    BR3010
10W CCT3 IP65 Floodlight BK
  BR3020
20W CCT3 IP65 Floodlight BK
  BR3030
 BR3050
30W CCT3 IP65 Floodlight BK
 50W CCT3 IP65 Floodlight BK
  BR3001
Plug In PIR for CCT3 Floodlight
   582
All in One CCT3 Floodlights
• LEDallinonefloodlightforresidentialapplications
• Highqualityblackaluminiumbodywithtoughened glass lens and extra long angled mounting bracket
allowing the unit to be fully rotational
• Incorporates 220V-240V on-board driver
• CCT switch on rear allows switching between
three colour temperatures (3000K/4000K/5000K)
• Fitted with an IP65 quick fit cable connector
• 3-year guarantee
• BS EN 60598-1
