P. 60

                    CABLE & ACCESSORIES Tapes & Jointing
 Double Seal Armoured Gland Pack
• BS6121PT1
• IP66 double seal
• Suitable for SWA cable
• 20-32mm Pack Qty 2
• 40-75mm Pack Qty 1
Resin Joint Kits Straight
• Underground resin joint kit
      Part No. Description
  EIW20/16PK
 Double seal outdoor cable gland 20mm thread super small 8.4mm-13.8mm Diameter Range
 EIW20SPK
Double seal outdoor cable gland 20mm thread small 11.8mm-15.8mm Diameter Range
 EIW20PK
 Double seal outdoor cable gland 20mm thread 15.5-20.8mm Diameter Range
 EIW25PK
 Double seal outdoor cable gland 25mm thread 20.3mm-27.5mm Diameter Range
 EIW32PK
  Double seal outdoor cable gland 32mm thread 26.7mm-33.5mm Diameter Range
 EIW40PK
Double seal outdoor cable gland 40mm thread 33mm-40.9mm Diameter Range
 EIW50SPK
 Double seal outdoor cable gland 50mm thread small 39.4mm-46.3mm Diameter Range
 EIW50PK
 Double seal outdoor cable gland 50mm thread 45.7mm-52.6mm Diameter Range
 EIW63SPK
  Double seal outdoor cable gland 63mm thread small 52.1mm-61.5mm Diameter Range
 EIW63PK
Double seal outdoor cable gland 63mm thread 58.4mm-65.3mm Diameter Range
 EIW75SPK
  Double seal outdoor cable gland 75mm thread small 64.8mm-73mm Diameter Range
 EIW75PACK
PVC Elect
 Double seal outdoor cable gland 75mm thread 71mm-78mm Diameter Range
ical Tape
    Part No. Description
  JK075-4
Straight Resin Joint 0.75-4mm2 (3/4 Core) Kit, Complete with Connectors Cable Diameter: 6-15mm Ø
 JK1.5-10
 Straight Resin Joint 1.5-10mm2 (3/4 Core) Kit, Complete with Connectors Cable Diameter: 8-20mm Ø
 JK10-25
 Straight Resin Joint 10-25mm2 (3/4 Core) Kit, Complete with Connectors Cable Diameter: 13-25mm Ø
 JK150-240
  Straight Resin Joint 150-240mm2 (3/4 Core) Kit, No Connectors Included Cable Diameter: 45-60mm Ø
 JK25-50
Straight Resin Joint 25-50mm2 (3/4 Core) Kit, Complete with Connectors Cable Diameter: 18-30mm Ø
 JK300-400
  Straight Resin Joint 300-400mm2 (3/4 Core) Kit, No Connectors Included Cable Diameter: 50-100mm Ø
 JK70-120
 Straight Resin Joint 70-120mm2 (3/4 Core) Kit, No Connectors Included Cable Diameter: 25-45mm Ø
    r
• PVC Electrical Tape
• BS3924 cat 2
Resin Joint Kits Branch
• Underground branch resin joint kit
    Part No. Description
   PVC19X33BLK
PVC19X33BROW
PVC Tape 19 x 33 Black
  PVC Tape 19 x 33 Brown
  Part No. Description
  PVC19X33GREY
PVC Tape 19 x 33 Grey
   JKB4
Branch Resin Joint 0.75-4mm2 (3/4 Core) Kit, Complete with Connectors Suitable for Main Cables 0.75-4mm2 (6-15mm Diameter) and Branch Off Cables 0.75-4mm2 (6-15mm Diameter)
  PVC19X33BLUE
PVC19X33G/Y
PVC Tape 19 x 33 Blue
  PVC Tape 19 x 33 Green/Yellow
  JKB10
Branch Resin Joint 1.5-10mm2 (3/4 Core) Kit, Complete with Connectors Suitable for Main Cables 1.5-10mm2 (8-20mm Diameter) and Branch Off Cables 1.5-10mm2 (8-20mm Diameter)
  PVC19X33RED
PVC Tape 19 x 33 Red
  PVC19X33ORA
PVC Tape 19 x 33 Orange
  PVC19X33GREEN
PVC Tape 19 x 33 Green
  JKB25
Branch Resin Joint 10-25mm2 (3/4 Core) Kit, Complete with Connectors Suitable for Main Cables 10-25mm2 (13-30mm Diameter) and Branch Off Cables 1.5-25mm2 (8-25mm Diameter)
  PVC19X33YELL
PVC19X33WHT
Specialist T
PVC Tape 19 x 33 Yellow
  PVC Tape 19 x 33 White
ape
    JKB50
Branch Resin Joint 25-50mm2 (3/4 Core) Kit, Connectors Sold Separate Suitable for Main Cables 25-50mm2 (18-30mm Diameter) and Branch Off Cables 1.5-35mm2 (8-35mm Diameter)
 • Self amalgamating black tape produces strong waterproof joints which insulates and prevents corrosion
   JKB120
Branch Resin Joint 70-120mm2 (3/4 Core) Kit, Connectors Sold Separate Suitable for Main Cables 50-120mm2 (25-45mm Diameter) and Branch Off Cables 1.5-35mm2 (8-35mm Diameter)
  JKB240
  Part No. Description
   CP62
Self Amalgamating Tape, 19mm x 10m
  CP62-25
Self Amalgamating Tape, 25mm x 10m
 JKB400
Branch Resin Joint 150-240mm2 (3/4 Core) Kit, Connectors Sold Separate Suitable for Main Cables 120-240mm2 (45-60mm Diameter) and Branch Off Cables 1.5-35mm2 (8-35mm Diameter)
 Branch Resin Joint 300-400mm2 (3/4 Core) Kit, Connectors Sold Separate Suitable for Main Cables 240-400mm2 (50-100mm Diameter) and Branch Off Cables 1.5-35mm2 (8-35mm Diameter)
  CP62-38
CP62-50
Self Amalgamating Tape, 38mm x 10m
  Self Amalgamating Tape, 50mm x 10m
     60
