                    CABLE & ACCESSORIES Junction Boxes
   • •
Blank Side Junction Boxes
Grey (RAL 7035) Operating temperature: -25°C to +60°C
Knockout Junction Boxes
• Grey (RAL 7035)
• Operating temperature: -25°C to +60°C
    Part No. Description
 CP1029
 80x120x50 IP54 Junction Box With Smooth Sides and Plain Blank Cover
 CP1030
  100x100x50 IP54 Junction Box With Smooth Sides and Plain Blank Cover
 CP1041
150x110x70 IP67 Junction Box With Smooth Sides and Plain Blank Cover
 CP1042
 190x145x80 IP67 Junction Box With Smooth Sides and Plain Blank Cover
 CP1047
  230x125x77 IP67 Junction Box With Smooth Sides and Plain Blank Cover
 CP1043
250x200x90 IP67 Junction Box With Smooth Sides and Plain Blank Cover
 CP1044
 310x230x130 IP67 Junction Box With Smooth Sides and Plain Blank Cover
 CP1048
 347x125x77 IP67 Junction Box With Smooth Sides and Plain Blank Cover
 CP1045
 400x300x130 IP67 Junction Box With Smooth Sides and Plain Blank Cover
 CP1049
  457x125x77 IP67 Junction Box With Smooth Sides and Plain Blank Cover
 CP1046
 480x400x120 IP55 Junction Box With Smooth Sides and Plain Blank Cover
  Deep Type Junction Boxes
 CP1059D
 80x120x120 IP54 Junction Box With Smooth Sides and Plain Deep Cover
 CP1060D
  100x100x120 IP54 Junction Box With Smooth Sides and Plain Deep Cover
 CP1061D
150x110x140 IP54 Junction Box With Smooth Sides and Plain Deep Cover
 CP1062D
 190x145x140 IP67 Junction Box With Smooth Sides and Plain Deep Cover
 CP1063D
 250x200x160 IP67 Junction Box With Smooth Sides and Plain Deep Cover
 CP1064D
  310x230x180 IP67 Junction Box With Smooth Sides and Plain Deep Cover
 CP1065D
 230x125x120 IP67 Junction Box With Smooth Sides and Plain Deep Cover
       • •
Glanded Junction Boxes
Grey (RAL 7035) Operating temperature: -25°C to +60°C
   Part No. Description
    CP1036
70x40 IP44 Round Junction Box Glanded Entry
  CP1037
85x45 IP44 Round Junction Box Glanded Entry
  CP1038
80x40 IP44 Round Junction Box Glanded Entry
  CP1039
80x120x50 IP54 Junction Box Glanded Entry
  CP1040
100x100x50 IP54 Junction Box Glanded Entry
 CP1453
  CP1051
150x110x70 IP54 Push Fit Lid Junction Box Glanded Entry
  CP1052
190x145x80 IpP65 Junction Box Glanded Entry
  CP1053
Deep Type Junction Boxes
250x200x90 IP65 Junction Box Glanded Entry
  CP1054
310x230x130 IP65 Junction Box Glanded Entry
     CP1359D
80x120x120 IP54 Multiple Size Cable Sleeve Entries and Plain Blank Cover
  CP1360D
100x100x120 IP54 Multiple Size Cable Sleeve Entries and Plain Blank Cover
  CP1361D
150x110x140 IP54 Multiple Size Cable Sleeve Entries and Plain Blank Cover
  CP1362D
190x145x140 IP65 Multiple Size Cable Sleeve Entries and Plain Blank Cover
  CP1363D
250x200x160 IP65 Multiple Size Cable Sleeve Entries and Plain Blank Cover
CP1474
250x200x90 IP67 Junction Box With M20/M25 Knock Out Entries and Plain Transparent Cover Impact Resistant Screw Down Transparent Deep
  CP1454
310x230x130 IP67 Junction Box With M20/M25 Knock Out Entries and Plain Transparent Cover Impact Resistant Screw Down Transparent Deep
  Transparent Cover Deep Type
  CP1471
150x110x140 IP67 Junction Box With M20/M25 Knock Out Entries and Plain Transparent Cover Impact Resistant Screw Down Transparent Deep
  CP1472
190x145x140 IP67 Junction Box With M20/M25 Knock Out Entries and Plain Transparent Cover Impact Resistant Screw Down Transparent Deep
  CP1473
250x200x160 IP67 Junction Box With M20/M25 Knock Out Entries and Plain Transparent Cover Impact Resistant Screw Down Transparent Deep
  310x230x180 IP67 Junction Box With M20/M25 Knock Out Entries and Plain Transparent Cover Impact Resistant Screw Down Transparent Deep
  CP1364D
310x230x180 IP65 Multiple Size Cable Sleeve Entries and Plain Blank Cover
     Together we
61
GENERATE VALUE
Part No. Description
  CP1236
70x40 IP44 Junction Box With M20/M25 Knock Out Entries and Plain Blank Cover
  CP1237
85x45 IP44 Junction Box With M20/M25 Knock Out Entries and Plain Blank Cover
  CP1238
80x80x40 IP44 Junction Box With M20/M25 Knock Out Entries and Plain Blank Cover
  CP1239
80x120x50 IP55 Junction Box With M20/M25 Knock Out Entries and Plain Blank Cover
  CP1240
100x100x50 IP55 Impact Resistant Screw Down Cover M20/M25 Knock Out Entries and Plain Blank Cover
  CP1251
150x110x70 IP55 Impact Resistant Screw Down Cover M20/M25 Knock Out Entries and Plain Blank Cover
  CP1252
190x145x80 IP67 Impact Resistant Screw Down Cover M20/M25 Knock Out Entries and Plain Blank Cover
  CP1253
250x200x90 IP67 Impact Resistant Screw Down Cover M20/M25 Knock Out Entries and Plain Blank Cover
  CP1254
310x230x130 IP67 Impact Resistant Screw Down Cover M20/M25 Knock Out Entries and Plain Blank Cover
  CP1259D
80x120x120 Deep Type, IP55 Junction Box With M20/M25 Knock Out Entries and Plain Blank Cover
  CP1260D
100x100x120 Deep Type, IP55 Junction Box With M20/M25 Knock Out Entries and Plain Blank Cover
  CP1261D
150x110x140 Deep Type, IP55 Junction Box With M20/M25 Knock Out Entries and Plain Blank Cover
  CP1262D
CP1263D
190x145x140 Deep Type, IP67 Junction Box With M20/M25 Knock Out Entries and Plain Blank Cover
  250x200x160 Deep Type, IP67 Junction Box With M20/M25 Knock Out Entries and Plain Blank Cover
  CP1264D
310x230x180 Deep Type, IP67 Junction Box With M20/M25 Knock Out Entries and Plain Blank Cover
  Transparent Cover
  CP1451
150x110x70 IP67 Junction Box With M20/M25 Knock Out Entries and Plain Transparent Cover Impact Resistant Screw Down Transparent Deep Cover
  CP1452
190x145x80 IP67 Junction Box With M20/M25 Knock Out Entries and Plain Transparent Cover Impact Resistant Screw Down Transparent Deep
