P. 57

                    CABLE & ACCESSORIES
Earthing & Insulated Terminals
Earth Bars
• Copper bar
• 650a
• M10 stud
• 35mm center
• 50mm x 6mm
Pre Insulated Terminals and Splices
   • Electro-tin plated Copper
Part No.
Red Terminals & Connectors
RR10
RR32
RR37
RR43
RR65
RR85
RF32
RF37
RF43
RF53
RF65
RB18
RP12
BSL15
RBM4
RFP63
RMP63
RSF4
Blue Terminals & Connectors
BR10
BR32
BR37
BR43
BR53
BR65
BR12
BF37
BF43
All Round Band BF53 BP12
BBM5
BFP63
BMP63
BB18
BSF5
BSL25
Yellow Terminals & Connectors
    Part No. Description
 EBC004
 4 Way Earth Bar 50 X 6
 EBC006
 6 Way Earth Bar 50 X 6
 EBC008
  8 Way Earth Bar 50 X 6
 EBC010
10 Way Earth Bar 50 X 6
 EBC012
 12 Way Earth Bar 50 X 6
 EBC104
 4 Way Earth Bar c/w 1 Link 50 X 6
 EBC106
  6 Way Earth Bar c/w 1 Link 50 X 6
 EBC108
8 Way Earth Bar c/w 1 Link 50 X 6
 EBC110
  10 Way Earth Bar c/w 1 Link 50 X 6
 EBC112
 12 Way Earth Bar c/w 1 Link 50 X 6
                    Earth Rods and Accessories
Description
Red Ring Terminal 10mm Stud Unit 100
Red Ring Terminal 3.2mm Stud Unit 100
Red Ring Terminal 3.7mm Stud Unit 100
Red Ring Terminal 4.3mm Stud Unit 100
Red Ring Terminal 6.5mm Stud Unit 100
Red Ring Terminal 8.5mm Stud Unit 100
Red Fork Terminal 3.2mm Stud Unit 100
Red Fork Terminal 3.7mm Stud Unit 100
Red Fork Terminal 4.3mm Stud Unit 100
Red Fork Terminal, 5.3mm Fork
Red Fork Terminal, 6.5mm Fork
Red Blade Terminal 18mm unit 100
Red Pin Terminal 12mm unit 100
Red Butt Splice Unit 100
Red Bullet Terminal Male 4mm Unit 100
Red Female Push on Terminal 6.3mm Unit 100
Red Male Push on Terminal 6.3mm Unit 100
Red Socket Terminal 4mm Unit 100
Blue Ring Terminal 10mm Stud Unit 100
Blue Ring Terminal 3.2mm Stud Unit 100
Blue Ring Terminal 3.7mm Stud Unit 100
Blue Ring Terminal 4.3mm Stud Unit 100
Blue Ring Terminal 5.3mm Stud Unit 100
Blue Ring Terminal 6.5mm Stud Unit 100
Blue Ring Terminal 12mm Stud Unit 100
Blue Fork Terminal, 3.7mm Fork Unit 100
Blue Fork Terminal, 4.3mm Fork Unit 100
Blue Fork Terminal, 5.3mm Fork Unit 100
Blue Pin Terminal 12mm Unit 100
Blue Bullet Terminal Male 5mm Unit 100
Blue Female push on Terminal 6.3mm Unit 100
Blue Male push on Terminal 6.3mm Unit 100
Blue Blade Terminal 18mm Unit 100
Blue Socket Terminal 5mm Unit 100
Blue Butt Splice Unit 100
           Part No. Description
 ER38
 3/8 Inch Earth Rod, 1200mm, Copper Bonded
 EC38
 3/8 Inch Earth Rod to Cable Clamp
 ER58
  5/8 Inch Earth Rod, 1200mm, Copper Bonded
 EC58
 5/8 Inch Earth Rod to Cable Clamp
       All Round Fixing Bands
• Steel band
              Part No. Description
    ARB12GALV
All Round Fixing Band 12mm Galvanized 10mtr
   ARB12RED
All Round Fixing Band 12mm Red 10mtr
   ARB12BLK
All Round Fixing Band 12mm Black 10mtr
   ARB12WHI
All Round Fixing Band 12mm White 10mtr
   ARB17BLK
All Round Fixing Band 17mm Black 10 Mtr
 YR43
YR53
YR65
Yellow Ring Terminal 4.3mm Stud Unit 100
Yellow Ring Terminal 5.3mm Stud Unit 100
Yellow Ring Terminal 6.5mm Stud Unit 100 Yellow Ring Terminal 8.5mm Stud Unit 100 Yellow Ring Terminal 10mm Stud Unit 100 Yellow Ring Terminal 12mm Stud Unit 100 Yellow Fork Terminal, 6.5mm Fork Unit 100 Yellow Blade Terminal 18mm Unit 100 Yellow Socket Terminal 5mm Unit 100 Yellow Butt Splice Unit 100
Yellow Female Push On Terminal 6.3mm Unit 100 Yellow Bullet Terminal Male 5mm Unit 100 Yellow Male Push On Terminal 6.3mm Unit 100
  ARB17GALV
All Round Fixing Band 17mm Galvenized 10mtr
   ARB17WHT
End Splic
All Round Fixing Band 17mm White 10mtr
     e
YR85 YR10 YR12 YF65 YB18 YSF5 BSL6 YFP63 YBM5 YMP63
     • 4-6mm2
• Maximum working temperature: +75°C
• Insulation Colour:
Natural (Semi-transparent White)
GENERATE VALUE
57
           Part No. Description
  NES6     End Splice, 4-6mm2 Unit 100
