Page 665 - Fegime - Electrical Product Guide Issue 1 V5
P. 665

                    LIGHTING Floods & Sign Lights
Siena Floodlights
     Siena 3CCT Floodlights
• 3000K/4000K/6000K CCT LED
• 3000K - 777 Lumens 4000K - 858 Lumens 6000K - 790 Lumens
• CRI: Ra>80
• Non-dimmable
• Integrated IP rated junction box
• IP65
• Class I
• L70 - 36,000hrs
Siena Floodlights • 115° Beam Angle
• CRI: Ra>82
• Non-dimmable
• Integrated IP rated junction box • IP65
• Class I
• L70 - 40,000hrs
Siena CL Floodlights • Class II
• IP65
• IK07
• Low Standby power typical parasitic power
Draw <0.3W
• Pre-wired with 1m Flex
• Polycarbonate contruction
• Suitable for High Saline Areas • L70 - 25,000hrs
Part No. Description
  KSR5280BLK
  Siena LED 10W 3CCT IP65 Floodlight
 KSR5281BLK
 Siena LED 10W 3CCT IP65 PIR Floodlight
 KSR5282BLK
Siena LED 20W 3CCT IP65 Floodlight
 KSR5283BLK
  Siena LED 20W 3CCT IP65 PIR Floodlight
 KSR5284BLK
Siena LED 30W 3CCT IP65 Floodlight
 KSR5285BLK
 Siena LED 30W 3CCT IP65 PIR Floodlight
 KSR5286BLK
  Siena LED 50W 3CCT IP65 Floodlight
 KSR5287BLK
 Siena LED 50W 3CCT IP65 PIR Floodlight
  Part No. Description
  KSR5310
  Siena CL LED 10W 4K IP65 Floodlight
 KSR5311
 Siena CL LED 10W 4K IP65 PIR Floodlight
 KSR5312
Siena CL LED 20W 4K IP65 Floodlight
 KSR5313
  Siena CL LED 20W 4K IP65 PIR Floodlight
 KSR5314
Siena CL LED 30W 4K IP65 Floodlight
 KSR5315
 Siena CL LED 30W 4K IP65 PIR Floodlight
 KSR5316
  Siena CL LED 50W 4K IP65 Floodlight
 KSR5317
 Siena CL LED 50W 4K IP65 PIR Floodlight
  Part No. Description
  KSR5288BLK
  Siena LED 100W 3K IP65 Floodlight
 KSR5289BLK
 Siena LED 100W 4K IP65 Floodlight
 KSR5290BLK
Siena LED 150W 3K IP65 Floodlight
 KSR5291BLK
  Siena LED 150W 4K IP65 Floodlight
 KSR5292BLK
 Siena LED 200W 3K IP65 Floodlight
 KSR5293BLK
 Siena LED 200W 4K IP65 Floodlight
    Spike Attachment for Siena Floodlights
Part No. Description
    KSR5294 Spike Attachment for Siena Floodlights
  Novelda Signlights
Novelda 3CCT Signlights
• Class II
• IP65
• 14W
• High CRI up to Ra85
• Supplied complete with driver
• 3 switchable colour temperatures
3000K/4000K/6000K
• Epistar LED Chip Technology
• Adjustable head via hex bolt
• 100° beam angle
• Optional extension mounting brackets
(KSR6103/6104)
• L70 - 30,000hrs
GENERATE VALUE
Novelda Signlight Brackets
   Part No. Description
   KSR6103
 Novelda 520mm Wall Bracket for KSR6102
 KSR6104
 Novelda 220mm Wall Bracket for KSR6102
   Part No. Description
    KSR6102 Novelda LED 14W 3CCT Signlight
   Together we
665
