660LIGHTINGTogether we GENERATE VALUE1-Circuit 230V Track System• 1-Circuit 230V track features metal to metal connections to optimise earthing• 1-Circuit 230V track is rated at 16A, giving a maximum lamp load of 3800W per track circuit (e.g. 76 x 50W spotlights)• 1-Circuit 230V track does not come with a Live End. Live Ends must be ordered separately• Figure of ‘8’ patterns cannot be constructed using this system• Live end, dead end and connector dimensions refer to length after insertion into trackPart No. Description Colour/FinishLengthT4-WH 1-Circuit Track, 230V, inc Dead End White 4ft / 1115mmT4-BL 1-Circuit Track, 230V, inc Dead End Black 4ft / 1115mmT4-SG 1-Circuit Track, 230V, inc Dead End Silver Grey 4ft / 1115mmT8-WH 1-Circuit Track, 230V, inc Dead End White 8ft / 2335mmT8-BL 1-Circuit Track, 230V, inc Dead End Black 8ft / 2335mmT8-SG 1-Circuit Track, 230V, inc Dead End Silver Grey 8ft / 2335mmT12-WH 1-Circuit Track, 230V, inc Dead End White 12ft / 3555mm16A Mains voltage track, connector & accessory system. Ideal for applications where spotlights may need to be frequently added or removed.1-Circuit 230V TrackTrack SystemsPart No. Description Colour/FinishLengthT38-WH Live End, Incoming Mains End Feed White 82mmT38-BL Live End, Incoming Mains End Feed Black 82mmT38-SG Live End, Incoming Mains End Feed Silver Grey 82mmT39-WH Centre Feed White 118 x 118mmT39-BL Centre Feed Black 118 x 118mmTDE1-WH Dead End With Fixing Screw White 3mmTDE1-BL Dead End With Fixing Screw Black 3mmTDE1-SG Dead End With Fixing Screw Silver Grey 3mmT23-WH Straight Connector White 8mmT23-BL Straight Connector Black 8mmT23-SG Straight Connector Silver Grey 8mmT20-WH Flexible Connector 0⁰ to 158⁰ White 160mmT20-BL Flexible Connector 0⁰ to 158⁰ Black 160mmT24-WH Adjustable Connector 90⁰ or 180⁰ White 90⁰ - 70 x 70mm 180⁰ - 105mmT24-BL Adjustable Connector 90⁰ or 180⁰ Black 90⁰ - 70 x 70mm 180⁰ - 105mmT25-WH ‘T' Connector, Dual Polarity White 70 x 105mmT25-BL ‘T' Connector, Dual Polarity Black 70 x 105mmT26-WH ‘X' Connector, Requires Two Live Ends White 105 x 105mmT26-BL ‘X' Connector, Requires Two Live Ends Black 105 x 105mmLive Ends, Dead Ends & ConnectorsPart No. Description Colour/FinishLengthT35(3000) Adjustable Suspension Wire - 3000mmT35(6000) Adjustable Suspension Wire - 6000mmT37F T Bar Attachment Clip Silver -T33-WH(500) Suspension Rod, Max Loading 10kg Per Rod White 500mmT33-BL(500) Suspension Rod, Max Loading 10kg Per Rod Black 500mmT33-SG(500) Suspension Rod, Max Loading 10kg Per Rod Silver Grey 500mmT33-WH(1000) Suspension Rod, Max Loading 10kg Per Rod White 1000mmT33-BL(1000) Suspension Rod, Max Loading 10kg Per Rod Black 1000mmT33-SG(1000) Suspension Rod, Max Loading 10kg Per Rod Silver Grey 1000mmSuspensions & T Bar AttachmentPart No. Description Colour/FinishT29-WH/S Switched Track Adapter - Pre Wired with 1500mm Cable, 1kg Max LoadWhiteT29-BL/S Switched Track Adapter - Pre Wired with 1500mm Cable, 1kg Max LoadBlackT32-WH/S Switched Track Adapter With RingPre Wired with 1500mm Cable, 5kg Max LoadWhiteT32-BL/S Switched Track Adapter With RingPre Wired with 1500mm Cable, 5kg Max LoadBlackTrack AdaptorsWhiteBlackSilver GreyT38 T39 TDE1T25 T26T24T24T23 T20T35 T37FT29 T32T33Dimensions (mm)180º90º
