Page 656 - Fegime - Electrical Product Guide Issue 1 V5
P. 656

                    LIGHTING
Fire Rated Downlights
Mauna
Mauna Plus Fixed & Tilt
The Mauna Plus 6W Dimmable Fire Rated Downlight is suitable
for 30, 60 and 90 minute applications. It has a switchable CCT
function so that the installer can select 3000K, 4000K or 6000K. The
downlights are dimmable with mains dimmer switches, compatible with a Kosnic emergency module and have a choice of additional magnetic bezel colours. The downlight is supplied with a white finish as standard plus a satin chrome magnetic bezel.
• Integrated dimmable driver
• Push-wire terminals loop-in loop-out
• Interchangeable magnetic bezels with different finishes
• Can be installed under Insulation layer
• Compact size
• Fixed white bezel as standard with add on satin chrome bezel included
• IP65 6W
• Compatible with the Kosnic Mains Emergency module
• CCT switching 3000K/4000K & 6500K
• 550lm (3000K), 550lm (4000K), 600lm (6000K)
   The Mauna 6W Dimmable Fire Rated Downlights are suitable for
30, 60 and 90 minute applications and may be installed under
insulation. These compact downlights can be dimmed with mains
dimmer switches and have a choice of interchangeable magnetic bezels with different finishes. The white bezel is supplied as standard.
• Integrated dimmable driver
• Interchangeable magnetic bezels with different finishes
• Can be installed under Insulation layer
• Compact size
• IP65
• Available in 3000K/4000K & 6500K
• Compatible with the Kosnic Mains Emergency module
• 6W
• 550lm (3000K), 550lm (4000K), 570lm (6500K)
  kosnic
             Brass Satin Chrome Brass Matt White
Mauna Pro
Black Chrome
Satin Chrome Matt Black
Polished Chrome
Tilt
Brass Satin Chrome Black Chrome
Brass Matt White Satin Chrome Matt Black
Mains EME
Fixed
Polished Chrome
            Mauna Pro 7W Dimmable Fire Rated Downlights are suitable for 30,
60 and 90 minute applications. It has an independant driver and a
junction box for fast connection. It has a switchable CCT function so
that the installer can select 3000K, 4000K or Dim to Warm, where the CCT changes from 3000K to 2000K as it dims. Mauna Pro is also dimmable with mains dimmer switches and have a choice of bezel colours. The white bezel is supplied as standard.
• Independent dimmable driver and a junction box for fast connection
• CCT Switchable (3000K/4000K/Dim To Warm 3000K-2000K)
• IP65, Class II
• Dimmable
• Can be installed under insulation
• Push-wire plug-in terminal with loop in and loop out
• 7W 480lm (3000K), 550lm (4000K)
Brass Satin Chrome Black Chrome
Brass Matt White Satin Chrome Matt Black Polished Chrome
The mains emergency module is an optional extra for a selection of
Kosnic LED downlights. It is designed for installing within the ceiling
void to provide a battery back-up supply in the event of a power
cut. It allows pass-through dimming from the mains but will switch to the battery supply in an emergency. The emergency module requires a permanent live un-switched supply to maintain the battery charge.
• Designed to work with Kosnic dimmable downlight ranges (Mauna, Erta & Napa)
• Mains DC output
• Easy plug & play installation
• Unique self-adhesive LED indicator pad for easy installation • 4 year battery warranty as standard
• 3W
              656
