Page 658 - Fegime - Electrical Product Guide Issue 1 V5
P. 658

                    LIGHTING
Bulkheads & LED DD Lamps
Ossa
Kosnic’s Ossa IP65 LED bulkhead is perfect for Kosnic’s K2D standard
and sensor LED lamps. The bulkhead includes an emergency option
and offers a low maintenance and robust solution to lighting in all
areas where a practical lighting solution is required. The bulkhead may be used as a simple utility style bulkhead without a trim or can be enhanced with one of the decorative trims to give a higher aesthetic appeal where required. Optional backlight rings are supplied with the 379mm trims but do not have to be used. Supplied with small white trim as standard.
• Choice of alternative decorative trims
• Slim profile design
• IP65 & vandal resistant (IK10)
• Optional plug-in emergency
module
• 20mm Conduit entry
• Conduit entries are not covered
by the decorative rings
• BESA box fitting pointsBESA box
fitting points
K2D
The K2D lamp takes a fresh approach to functional lighting with a
design that offers a built-in microwave sensor, selectable 9W, 12W
or 18W output and 3000K, 4000K or 5000K CCT options on a single
lamp. The lamps are compatible with Kosnic’s plug-in emergency modules so there are no barriers to fitting LEDs in commercial fittings. The products bring the energy saving capabilities of LED technology to the commercial environment and the lamps may quickly replace existing fluorescent lamps with no rewiring where space allows.
Blanca
Kosnic’s IP65 Blanca LED bulkhead for LED DD lamps offers a low
maintenance and robust solution to lighting in corridors, staircases,
security zones, thoroughfares and other areas where a practical
lighting solution is required. The standard bulkhead can be used as a utility style bulkhead without a trim or can be enhanced with one of the decorative trims to give a higher aesthetic appeal where required.
• Choice of clip-on rings
• IP65 and vandal resistant (IK10)
• Use with Kosnic LED DD range
• Option of base with emergency module
• 5 Years Standard Warranty
• Built-in emergency option available
• Optional plug in self test emergency module available
• 20mm Conduit entry & BESA box fitting points
LED DD
Kosnic’s range of LED DD lamps takes a fresh approach to functional
lighting with a design philosophy offering plug-in emergency packs
and optional microwave sensor versions so that there are no barriers
to retrofitting LEDs in commercial fittings. The products bring the energy saving capabilities of LED technology to the commercial environment and the lamps can quickly replace fluorescent DD lamps with little or no rewiring.
• Save energy up to 65% compared with a fluorescent DD lamp with magnetic ballast.
• For maximum energy savings, bypass all control gear and supply directly from the mains.
• Single side high lumen output for light only where it’s needed. • Long life of 30,000h.
• Compatible with Kosnic’s emergency modules.
• Dusk to Dawn lamp available
• Motion sensor & built in corridor function lamps available
                    • Switchable wattage 9W, 12W or 18W
• Switchable CCT 3000K, 4000K or 5000K
• 2 products with a possibility of 27 settings
• Single side high lumen output for light only
where it’s needed
• Compatible with Kosnic’s standard and
self-test emergency modules
• Standard 5-year warranty
• Motion sensor & built in corridor
function lamps available with optional 10% dimming corridor function
DD EME
Sensor
Standard
     The DD emergency module is an optional extra for the latest Kosnic
LED DD & K2D lamps. It is designed for installing within the fitting to
provide a battery back-up supply in the event of a power cut through
the supplementary socket on the LED DD lamp. The emergency module requires a permanent live un-switched supply to maintain the battery charge. Available in standard & Self test
• Built-in self-test function according to BS-EN-62034-2012
• Easy Plug & Play installation
• For maintained or non-maintained
emergency lighting systems
• Internal Li-Ion battery with improved
lifespan
• Dual colour LED indicator for error
reporting built into
• 4YR Battery warranty
• Suitable for all Kosnic LED DD
& K2D lamps
• Easy battery replacement
Dusk to Dawn
Sensor
Standard
    658
Together we
GENERATE VALUE
  Scan QR code to view the product codes

















   656   657   658   659   660
