                    LIGHTING
Panels & Controls
Alden
The Kosnic Alden LED panel offers direct backlit lighting with wide-
angle optics to achieve even light distribution across the surface of
the luminaire and is an easy-to-retrofit replacement for in-lay ceiling
tile fittings. The panels are supplied with flicker-free drivers as standard and suitable for visually demanding non-transient task areas such as offices and educational premises where users require high quality lighting to maintain well-being.
• Save up to 50% energy usage compared to traditional fluorescent fittings
• TP(a) rated diffuser
• Square edge tray with robust structure to allow even light distribution
around the edge
• DALI, 1-10V (0-10V) and PUSH alternative driver available
• IP44 when ceiling recess mounted
• Flicker free
• UGR<19
UEM II
The Universal Emergency Module (UEM) is suitable for class
III luminaires with integrated LEDs and separate LED drivers.
The DC voltage output is adjusted within the UEM’s limits to the
level required to operate the luminaire load and then the current is limited to ensure an operation time of three hours. This gives a typical power output of 3W but will depend on the characteristics of the luminaire. The UEM II can be installed within a luminaire or within the ceiling void. In the event of a power cut the replaceable internal lithium-ion battery will supply the luminaire through a connection that must be made between the LED driver output and LED luminaire input.
• Loop-in and loop-out push-wire terminals
• Built-in self-test function according to BS-EN-62034-2012
• Designed for use with all LED luminaires (class III) with external driver
• Easy Plug & Play installation
• For maintained or non-maintained emergency lighting systems
• Internal Li-ion battery with improved lifespan
• Easy battery replacement
• Standard 4 year battery warranty
• EME driver isolation - LED driver & LED light source are switched off in
Alden Pro
The Kosnic Alden-Pro LED panel offers direct backlit lighting with
wide-angle optics to achieve even light distribution across the surface
of the luminaire and is an easy-to-retrofit replacement for in-lay
ceiling tile fittings. The panels are CCT switchable so you can select from a range of colour temperatures. They are also supplied with polycarbonate diffusers and flicker-free drivers as standard, suitable for visually demanding non-transient task areas such as offices and educational premises where users require high quality lighting to maintain well-being.
• Switchable CCT (3000K/4000K/6500K)
• Switchable wattage for 1195mm x 595mm and 1195mm x 295mm models
• TP(a) rated diffuser
• Square edge tray with robust structure to allow even light distribution
around the edge
• DALI, 1-10V (0-10V) and PUSH alternative driver available
• IP44 when ceiling recess mounted
• Flicker free
• UGR<19
Dimmable Driver
DALI 2, 1-10V (0-10V) & PUSH button dimmable driver
• Multiple constant current output selections (300- 900mA)
• DALI dimmable
• 1-10V (0-10V) dimmable
• Primary PUSH retractive switch dimmable
• Flicker-free
• Push-fit terminals
• Output overload protection with automatic restart
• Output short-circuit shutdown with automatic restart • Overheating protection.
• Class II IP20 independent driver
• SELV equivalent
• Synchronisation function for up to 15 drivers
            emergency mode
Leads included
Connection Lead
Recessed Holder for LED Indicator
GENERATE VALUE
Red / Green LED Indicator
Push Switch (Self-test version)
Self-adhesive LED indicator pad
