670LIGHTINGTogether we GENERATE VALUE1-Circuit 230V Track System%u2022 1-Circuit 230V track features metal to metal connections to optimise earthing%u2022 1-Circuit 230V track is rated at 16A, giving a maximum lamp load of 3800W per track circuit (e.g. 76 x 50W spotlights)%u2022 1-Circuit 230V track does not come with a Live End. Live Ends must be ordered separately%u2022 Figure of %u20188%u2019 patterns cannot be constructed using this system%u2022 Live end, dead end and connector dimensions refer to length after insertion into trackPart No. Description Colour/FinishLengthT4-WH 1-Circuit Track, 230V, inc Dead End White 4ft / 1115mmT4-BL 1-Circuit Track, 230V, inc Dead End Black 4ft / 1115mmT4-SG 1-Circuit Track, 230V, inc Dead End Silver Grey 4ft / 1115mmT8-WH 1-Circuit Track, 230V, inc Dead End White 8ft / 2335mmT8-BL 1-Circuit Track, 230V, inc Dead End Black 8ft / 2335mmT8-SG 1-Circuit Track, 230V, inc Dead End Silver Grey 8ft / 2335mmT12-WH 1-Circuit Track, 230V, inc Dead End White 12ft / 3555mm16A Mains voltage track, connector & accessory system. Ideal for applications where spotlights may need to be frequently added or removed.1-Circuit 230V TrackTrack SystemsPart No. Description Colour/FinishLengthT38-WH Live End, Incoming Mains End Feed White 82mmT38-BL Live End, Incoming Mains End Feed Black 82mmT38-SG Live End, Incoming Mains End Feed Silver Grey 82mmT39-WH Centre Feed White 118 x 118mmT39-BL Centre Feed Black 118 x 118mmTDE1-WH Dead End With Fixing Screw White 3mmTDE1-BL Dead End With Fixing Screw Black 3mmTDE1-SG Dead End With Fixing Screw Silver Grey 3mmT23-WH Straight Connector White 8mmT23-BL Straight Connector Black 8mmT23-SG Straight Connector Silver Grey 8mmT20-WH Flexible Connector 0%u2070 to 158%u2070 White 160mmT20-BL Flexible Connector 0%u2070 to 158%u2070 Black 160mmT24-WH Adjustable Connector 90%u2070 or 180%u2070 White 90%u2070 - 70 x 70mm 180%u2070 - 105mmT24-BL Adjustable Connector 90%u2070 or 180%u2070 Black 90%u2070 - 70 x 70mm 180%u2070 - 105mmT25-WH %u2018T' Connector, Dual Polarity White 70 x 105mmT25-BL %u2018T' Connector, Dual Polarity Black 70 x 105mmT26-WH %u2018X' Connector, Requires Two Live Ends White 105 x 105mmT26-BL %u2018X' Connector, Requires Two Live Ends Black 105 x 105mmLive Ends, Dead Ends & ConnectorsPart No. Description Colour/FinishLengthT35(3000) Adjustable Suspension Wire - 3000mmT35(6000) Adjustable Suspension Wire - 6000mmT37F T Bar Attachment Clip Silver -T33-WH(500) Suspension Rod, Max Loading 10kg Per Rod White 500mmT33-BL(500) Suspension Rod, Max Loading 10kg Per Rod Black 500mmT33-SG(500) Suspension Rod, Max Loading 10kg Per Rod Silver Grey 500mmT33-WH(1000) Suspension Rod, Max Loading 10kg Per Rod White 1000mmT33-BL(1000) Suspension Rod, Max Loading 10kg Per Rod Black 1000mmT33-SG(1000) Suspension Rod, Max Loading 10kg Per Rod Silver Grey 1000mmSuspensions & T Bar AttachmentPart No. Description Colour/FinishT29-WH/S Switched Track Adapter - Pre Wired with 1500mm Cable, 1kg Max LoadWhiteT29-BL/S Switched Track Adapter - Pre Wired with 1500mm Cable, 1kg Max LoadBlackT32-WH/S Switched Track Adapter With RingPre Wired with 1500mm Cable, 5kg Max LoadWhiteT32-BL/S Switched Track Adapter With RingPre Wired with 1500mm Cable, 5kg Max LoadBlackTrack AdaptorsWhiteBlackSilver GreyT38 T39 TDE1T25 T26T24T24T23 T20T35 T37FT29 T32T33Dimensions (mm)180%u00ba90%u00ba
