671LIGHTINGTogether we GENERATE VALUEFire-Rated DownlightsV50™ Pro Anti-GlarePart No. Description Colour Temp. LED Lumens LpcWJC1019/WH V50 Pro Anti-Glare with White Bezel 3000K & 4000K 6W 650/700 108/116JC1019/WHBLK V50 Pro Anti-Glare with White Bezel & Inner Black Cone 3000K & 4000K 6W 650/700 108/116JC1019/BLK V50 Pro Anti-Glare with Black Bezel 3000K & 4000K 6W 650/700 108/116• 20mm recessed lens for reduced glare• V50™ Pro driver with double hinge terminal cover for ease of installation• White, black and white/black baffle options• Maintains 60° beam angle• Slim profile 3mm white bezel• Low profile design, for installations in shallow 50mm ceiling voids• Selectable colour temperature from beneath the ceiling, 3000K & 4000K• Tested for use in Solid and I-joist ceilings*Discreet recessed light sourceV50™ Pro Retrofit• Slim profile 3mm white bezel • Allows for retrofit where larger downlights were previously installed• Covers ceiling cut-outs damaged by previous fittings• Slim profile 3mm white bezel• Low profile design, for installations in shallow 50mm ceiling voids• Selectable colour temperature from beneath the ceiling, 3000K & 4000K• Tested for use in Solid and I-joist ceilings*For retrofit applications with larger cut-outsV50™ Pro IP65 Tilt• IP65 slim bezel version of V50™ Tilt• Die-cast aluminium bezels• 350° rotatable and 20° tiltable• Low profile design, for installations in shallow 50mm ceiling voids• Selectable colour temperature from beneath the ceiling, 3000K & 4000K• Tested for use in solid and I-joist ceilings*Suitable for use in bathrooms and wet areasPart No. Description Colour Temp. LED Lumens LpcWJC1013/WH V50 Pro Retrofit 100mm 3000K & 4000K 6W 650/700 108/116JC1015/WH V50 Pro Retrofit 135mm 3000K & 4000K 6W 650/700 108/116JC1017/WH V50 Pro Retrofit 170mm 3000K & 4000K 6W 650/700 108/116Part No. Description Colour Temp. LED Lumens LpcWJC1026/BN V50 Pro Tilt IP65 with Brushed Nickel Bezel 3000K & 4000K 6W 650/700 108/116JC1026/CH V50 Pro Tilt IP65 with Chrome Bezel 3000K & 4000K 6W 650/700 108/116JC1026/WH V50 Pro Tilt IP65 with White Bezel 3000K & 4000K 6W 650/700 108/116*see jcc.co.uk for full certification details. It is the responsibility of the installer to ensure compliance with all the relevant regulations.
