                    CABLE & ACCESSORIES
Fire Resistant Cable
Nexans Alsecure® NX600
Nexans Alsecure® NX600 is a low smoke, halogen free, fire resistant cable approved for applications with survival times of 30, 60 and 120 minute as described in BS8519 and is designed for use with fire safety engineering systems in buildings such as:
• The supply and control of smoke and fire barriers
• Smoke control equipment e.g. dampers, curtains, fans
• Fire-fighting and evacuation lifts
• Sprinkler systems
• Wet riser pumps
• Plus other systems which help to ensure the
safest evacuation and assist in the firefighting stages of a fire
Construction
Alsecure® NX600 are armoured fire resistant cables for 600/1000V with low emission of smoke and corrosive gases when exposed to fire to further reduce the risk to life. They are designed as per BS7846 standard and are approved for the F2 and F120 fire test as per BS8491 standard.
The cable is a halogen free, mica and XLPE insulated, LSF bedded, steel wire armoured and LSF sheathed cable with annealed copper conductors. In addition, the Alsecure cables have no extra tapes to remove, are easy to strip and retain their memory making them easy to install.
nexans
    Full fire test performance
• BS 7846 F2-F120
• BS 8519 cat1-2-3
• BS 8491 F120
• IEC 60332-3-24
• IEC 60267-2.1/2.2
• IEC 61034-2
   Part No. Description
  10539717
 NX600 3x6 mm2
 10539718
 NX600 3x10 mm2
 10539719
 NX600 3x16 mm2
 10544555
  NX600 3x25 mm2
 10544556
NX600 3x35 mm2
 10544557
 NX600 3x50 mm2
 10544558
 NX600 3x70 mm2
 10544559
  NX600 3x95 mm2
 10544560
NX600 3x120 mm2
 10544561
 NX600 3x150 mm2
 10544562
 NX600 3x185 mm2
 10544563
  NX600 3x240 mm2
 10544564
 NX600 3x300 mm2
 10544565
 NX600 3x400 mm2
  Part No. Description
  10539731
 Nx600 4X6 mm2
 10539732
 Nx600 4X10 mm2
 10539733
 Nx600 4X16 mm2
 10539734
  Nx600 4X25 mm2
 10539735
Nx600 4X35 mm2
 10539736
 Nx600 4X50 mm2
 10539737
 Nx600 4X70 mm2
 10539738
  Nx600 4X95 mm2
 10539739
Nx600 4X120 mm2
 10539740
 Nx600 4X150 mm2
 10539741
 Nx600 4X185 mm2
 10539742
  Nx600 4X240 mm2
 10544397
 Nx600 4X300 mm2
 10544566
 Nx600 4X400 mm2
