Cable & Accessories29 Together we GENERATE VALUEKing Joints %u2013 Armoured CablesPart No. Description Dimensions Max O/DKing Joint L6 Arm 1.5-4mm%u00b2 5 Core SWA/1.5-6mm%u00b2 5 Core Flex105 x 55 x 55mm 20.5mmKing Joint L10 Arm 2.5-10mm%u00b2 5 Core SWA/FLEX 180 x 60 x 60mm 24mmKing Joint L25 Arm 4-25mm%u00b2 5 Core SWA/FLEX 210 x 65 x 65mm 31mmY6-Arm T: 4 x 1,5 - 6mm%u00b2 - B: 4 x 1,5 - 4mm%u00b2T: 5 x 1,5 - 6mm%u00b2 - B: 5 x 1,5 - 4mm%u00b2138 x 60 x 37mm T: 22,5mmB: 18,5mmY16 Arm T: 4 x 4 - 16mm%u00b2 - B: 4 x 1,5 - 4mm%u00b2T: 5 x 4 - 16mm%u00b2 - B: 5 x 1,5 - 4mm%u00b2194 x 74 x 43mm T: 26mmB: 18,5mmL25 Arm 4 x 10 - 25mm%u00b25 x 10 - 25mm%u00b2210 x 65 x 65mm 31mm%u2022 Re-enterable and reusable%u2022 Completely non-toxic%u2022 Suitable for permanent submersion in water or underground%u2022 Di-electric strength >23 Kv/mm%u2022 Fire resistant%u2022 Halogen- free gelApprovals:%u2022 IPX8 %u2013 officially tested by IMQSuper BlockPart No. Colour Up toSUPERBLOCK3 Orange 3 x 4mm2SUPERBLOCK3W Black 3 x 4mm2SUPERBLOCK5 Orange 5 x 4mm2SUPERBLOCK5W Black 5 x 2.5mm2%u2022 For straight or branch connections of 3 or 5 rigid or flexible wires up to 4 mm%u00b2%u2022 Tool-less%u2022 Can be powered immediately - Always re-enterable%u2022 IP68%u2022 Halogen- free gel & UV resistant%u2022 Pre-filled with conforming viscoelastic gel, not classified as hazardous%u2022 Re-usable%u2022 No shelf life%u2022 Dimensions: W57 x D47 x H26mmPart No. Description Dimensions Cable Range Colour PackBARNEY c/w 2 Core 10 Amp 75 x 28 x 19mm 6-10mm Grey 1BARNEY-N c/w 2 Core 10 Amp 75 x 28 x 19mm 6-10mm Black 1BARNEY-MP c/w 2 Core 10 Amp 75 x 28 x 19mm 6-10mm Grey 10FRED c/w 3 Core 10 Amp 80 x 36 x 23mm 8-13mm Grey 1FRED-N c/w 3 Core 10 Amp 80 x 36 x 23mm 8-13mm Black 1FRED-MP c/w 3 Core 10 Amp 80 x 36 x 23mm 8-13mm Grey 10FRED-4 3 x 4mm2 80 x 36 x 23mm 8-13mm Grey 1FRED-4-N 3 x 4mm2 80 x 36 x 23mm 8-13mm Black 1Little Joint%u2022 Re-enterable and reusable%u2022 No shelf life and completely non-toxic%u2022 Fully submersible & can be used undergroundApprovals:%u2022 IP68 - officially tested by IMQ%u2022 IP69K protection%u2022 Halogen free & UV resistant%u2022 Self- extinguishing & resistant to heat & FireIdeal for connections in lighting systems, for gardens, steps & sideways.The new Gel Box with integrated lever connectors: ready, complete, submersible and compact.The GEL BOX range, designed in 2015, is enriched with a new range of compact and waterproof connecting devices. For increasingly secure and high-performance connections over time.Pre-filled gel IPX8 cable joints suitable for armoured and unarmoured cables complete with connector to make installation very quick and easy.Raytech - Waterproof ConnectionsPart No. Description Dimensions Cable Range Colour PackDINO 4 x 4mm2 125 x 43 x 35mm 10 - 16mm Grey 1DINO - N 4 x 4mm2 125 x 43 x 35mm 10 - 16mm Black 1DINO 6 3 x 6mm2 125 x 43 x 35mm 10 - 16mm Grey 1BETTY/4 5 x 4mm2 145 x 46 x 35mm 10 - 16mm Grey 1BETTY/4 - N 5 x 4mm2 145 x 46 x 35mm 10 - 16mm Black 1BETTY/6 5 x 6mm2 145 x 46 x 35mm 14 - 19mm Grey 1BETTY/6 - N 5 x 6mm2 145 x 46 x 35mm 14 - 19mm Black 1TOM 5 x 16mm2 180 x 53 x 42mm 19 - 23mm Grey 1TOM - N 5 x 16mm2 180 x 53 x 42mm 19 - 23mm Black 1
