P. 26

                    CABLE & ACCESSORIES
Enclosures, Junction Boxes & Bags
AS Range
HT Mild Steel Wall Encolsures
BRES GRP Moulded Polyester Enclosures
        • Double insulated
• IK08
• IP56
• Installation temperature -15°C to +60°C
• RAL7035
Insulating Junction Boxes
Bags
• Easily reversible door, as well as enabling 110o door opening
• Self extinguishing material as per ASTM D635 • Resistant against rusting and corrosion by
chemical or atmospheric agents
• Door hinges allow a 180° opening
• Plinths and other accessories available on
request • IK10
• IP66
• Maximum working temperature ranges from
-30°C to +120°C • RAL7035
GRP IP66 Wall Mounted Enclosures
• Watertight gasket to guarantee the degree of protection
• Customised enclosures can be produced to accommodate specific dimensions, RAL colour requirements, and cable entries or cut outs (moq would apply)
• IK10
• IP66
• Suitable for use indoors
• RAL7035
Mild Steel Wall Enclosures
  Part No. Description
 AS05
 Junction Box 123x83x62mm
 AS15
 Junction Box 103x103x62mm
 AS25
  Junction Box 154x113x77mm
 AS35
Junction Box 193x144x79mm
 AS45
 Junction Box 242x190x90mm
 AS55
  Junction Box 305x225x126mm
 AS65
 Junction Box 390x310x128mm
       Part No. Description
   HT302515 Enclosure 300x250x150mm
 HT302520 Enclosure 300x250x200mm
 HT303015 Enclosure 300x300x150mm
 HT303020 Enclosure 300x300x200mm
HT403015 Enclosure 500x300x150mm
    Tool Bag Toolbag
HT403020 Enclosure 400x300x200mm
 HT404020 Enclosure 400x400x200mm
  HT504015 Enclosure 500x400x150mm
 HT504020 Enclosure 500x400x200mm
 HT504025 Enclosure 500x400x250mm
  • Removable shoulder strap
• Internal and external pockets
• Available in small, medium and large sizes
• Double insulation
• IK08
• IP55
• Installation temperature -15°C to +60°C
• RAL7035
Adaptable Junction Box with Opaque Lid
GENERATE VALUE
HT505025 Enclosure 500x500x250mm
 HT604015 Enclosure 600x400x150mm
 HT604020 Enclosure 600x490x200mm
 HT605020 Enclosure 600x500x200mm
 HT605025 Enclosure 600x500x250mm
 HT606020 Enclosure 600x600x200mm
 HT606025 Enclosure 600x600x250mm
 HT606030 Enclosure 600x600x300mm
 HT705020 Enclosure 700x500x200mm
 HT705025 Enclosure 700x500x250mm
  Part No. Description
HT806020 Enclosure 800x600x200mm
 HT806025 Enclosure 800x600x250mm
 HT806030 Enclosure 800x600x300mm
   HT808030 Enclosure 800x800x300mm
   BGS
Tool Bag 300x170x220mm
HT1008030 Enclosure 1000x800x300mm
    BGM
ASH45
 BGL
Tool Bag 400x220x320mm
Tool Bag Large
HT10010030 Enclosure 1000x1000x300mm
  HT12080300 Enclosure 1200x800x300mm
ASH55
Junction Box 220x150x150mm
  Junction Box 300x220x150mm
      26
Together we
Part No. Description
  BRES325
Enclosure 300x250x140mm
  BRES43
Enclosure 400x300x200mm
  BRES44
BRES54
Enclosure 400x400x200mm
  Enclosure 500x400x200mm
  BRES64
Enclosure 600x400x230mm
  BRES65
Enclosure 600x500x230mm
  BRES83
Enclosure 800x300x230mm
  BRES86
ASH
Enclosure 800x600x300mm
   Part No. Description
  ASH15
Junction Box 110x110x112mm
  ASH25
Junction Box 150x110x150mm
  ASH35
Junction Box 150x150x150mm
