                    CABLE & ACCESSORIES Gel Covers
Raytech Gel Covers
Pre-filled IPX8 gel covers suitable for either strip connectors or new style Wago 221 connectors.
Simply snap them shut and you will have complete protection from water. The small cover will accommodate up to 2 pole 10 amp strip connectors or 2 Wago 221-212 lever arm connectors. The larger 3 pole 15 amp strip connectors or 3 Wago 221-213 lever arm connectors. Available now in green or transparent.
• Non toxic, no shelf life and non oily Approvals:
      • Re-enterable and reusable even after long periods of operation
• Operating temperature +90°C
• Can be used underground
• CEI EN50393 with connectors complying with EN 61238-1 (with additional testing of pushing water through the cable cores)
• Class 2 in accordance with CEI 64-8 • IPX8 - officially tested by IMQ
Part No.
Dimensions
Max Cable
Colour
Pack Size
 Gel Cover 4
  61 x 35 x 28mm
  2 core 4mm2
  Green
  1
 Mammut Gel Cover 4
61 x 35 x 28mm
2 core 4mm2
Green
8
 Gel Cover 6
 63 x 41 x 28mm
 3 core 6mm2
 Green
 1
 Mammut Gel Cover 6
 63 x 41 x 28mm
 3 core 6mm2
 Green
 6
 Ohm
  61 x 35 x 28mm
  2 core 4mm2
  Clear
  1
 Ohm-P11
61 x 35 x 28mm
2 core 4mm2
Clear
11
 Bar
  63 x 41 x 28mm
  3 core 6mm2
  Clear
  1
 Bar-P9
 63 x 41 x 28mm
 3 core 6mm2
 Clear
 9
     Gel Box Line
 A range of very small pre-filled gel boxes designed to snap around the most commonly used type of connectors. They are suitable for both lever arm and strip connectors.
   • Fully submersible
• Re-enterable and reusable
• Non-toxic and no shelf life
• Operating temperature +90°C
• Can be used underground
Approvals:
• CEI EN50393 as applicable
• IPX8 – officially tested by IMQ
Part No.
Dimensions
Through Connect
Lever Arm
Pack Size
 Isaac4
 30 x 27 x 23mm
 2 core 2.5mm2
 3 Arms
 4
 Isaac4-MP
 30 x 27 x 23mm
 2 core 2.5mm2
 3 Arms
 50
 Pascal6
 36 x 37 x 26mm
 3 core 4mm2
 5 Arms
 2
 Pascal6-MP
  36 x 37 x 26mm
  3 core 4mm2
  5 Arms
  25
 Watt
30 x 42 x 26mm
n/a
5 Arms
2
 Watt-MP
 30 x 42 x 26mm
 n/a
 5 Arms
 25
 Joule
 33 x 52 x 26mm
 n/a
 6 Arms
 1
 Joule-MP
 33 x 52 x 26mm
 n/a
 6 Arms
 20
 Kelvin
  52 x 53 x 29mm
  3 core 6mm2
  n/a
  1
 Kelvin-MP
 52 x 53 x 29mm
 3 core 6mm2
 n/a
 20
    Happy Line
Very small pre-filled gel boxes that allow 3 different ways of entry. Suitable for strip connectors and lever arm connectors.
• Fully submersible
• Re-enterable and reusable
• Non-toxic and no shelf life
• Operating temperature +90°C
• Can be used underground
GENERATE VALUE
Approvals:
• CEI EN50393 as applicable
• IPX8 – officially tested by IMQ
Ke
lvin
Isaac4
  Watt
      Part No.
Dimensions
Through Connect
Lever Arm
Colour
Pack Size
 Happy 0
 41 x 28 x 19mm
 2 core 2.5mm2
 3 Arms
 Orange
 4
 Happy 0 Box 12
 41 x 28 x 19mm
 2 core 2.5mm2
 3 Arms
 Clear
 12
 Happy 1
  45 x 37 x 24mm
  3 core 2.5mm2
  5 Arms
  Silver
  2
 Happy 1 Box 10
45 x 37 x 24mm
3 core 2.5mm2
5 Arms
Clear
10
 Happy 2
  53 x 39 x 24mm
  3 core 4mm2
  6 Arms
  Yellow
  1
 Happy 2 Box 7
 53 x 39 x 24mm
 3 core 4mm2
 6 Arms
 Clear
 7
