                                    18CABLE & ACCESSORIESTogether we GENERATE VALUERaytech - Waterproof ConnectionsHappy Line• Fully submersible• Re-enterable and reusable• Non-toxic and no shelf life• Operating temperature +90°C• Can be used undergroundApprovals:• CEI EN50393 as applicable• IPX8 – officially tested by IMQPart No. Dimensions Through ConnectLever ArmColour Pack SizeHappy 0 41 x 28 x 19mm 2 core 2.5mm² 3 Arms Orange 4Happy 0 Box 12 41 x 28 x 19mm 2 core 2.5mm² 3 Arms Clear 12Happy 1 45 x 37 x 24mm 3 core 2.5mm² 5 Arms Silver 2Happy 1 Box 10 45 x 37 x 24mm 3 core 2.5mm² 5 Arms Clear 10Happy 2 53 x 39 x 24mm 3 core 4mm² 6 Arms Yellow 1Happy 2 Box 7 53 x 39 x 24mm 3 core 4mm² 6 Arms Clear 7Super ClikPart No. Description Dimensions Max O/DSuper Clik 0 Up to 3 Core 6mm² Flex or 3 Core 4mm² and 2.5mm° Branch95 x 43 x 28mm14mmSuper Clik 1 Up to 5 Core 6mm² Straight or 5 Core 5mm² and 5 Core 2.5mm² Branch150 x 56 x 30mm20.5mmSuper Clik 2 Up to 5 Core 16mm² Straight or5 Core 10mm² and 5 Core 6mm² Branch220 x 85 x 46mm30mmSuper Clik 3 Up to 4 Core 25mm² and 4 Core 16mm² for the Branch220 x 85 x 46mm30mmRaytech Gel CoversPart No. Dimensions Max Cable Colour Pack SizeGel Cover 4 61 x 35 x 28mm 2 core 4mm² Green 1Mammut Gel Cover 4 61 x 35 x 28mm 2 core 4mm² Green 8Gel Cover 6 63 x 41 x 28mm 3 core 6mm² Green 1Mammut Gel Cover 6 63 x 41 x 28mm 3 core 6mm² Green 6Ohm 61 x 35 x 28mm 2 core 4mm² Clear 1Ohm-P11 61 x 35 x 28mm 2 core 4mm² Clear 11Bar 63 x 41 x 28mm 3 core 6mm² Clear 1Bar-P9 63 x 41 x 28mm 3 core 6mm² Clear 9• Non toxic, no shelf life and non oily• Re-enterable and reusable even after long periods of operation• Operating temperature +90°C• Can be used undergroundApprovals:• CEI EN50393 with connectors complying with EN 61238-1 (with additional testing of pushing water through the cable cores)• Class 2 in accordance with CEI 64-8• IPX8 - officially tested by IMQPrefilled gel cable joints suitable for unarmoured cables complete with connectors. Armoured versions also available.• Re-enterable and reusable• Non-toxic and no shelf life• Suitable for permanent submersion in water or undergroundApprovals:• CEI EN50393 (with additional testing of pushing water through the cable cores)• IPX8 - officially tested by IMQVery small pre-filled gel boxes that allow 3 different ways of entry. Suitable for strip connectors and lever arm connectors.Pre-filled IPX8 gel covers suitable for either strip connectors or new style Wago 221 connectors. Simply snap them shut and you will have complete protection from water. The small cover will accommodate up to 2 pole 10 amp strip connectors or 2 Wago 221-212 lever arm connectors. The larger 3 pole 15 amp strip connectors or 3 Wago 221-213 lever arm connectors. Available now in green or transparent.
