P. 20

                    CABLE & ACCESSORIES Single Part Compounds
Wonder Gel, Wonder Gel Invisible, Monogel and Wonder Fluid
Single component re-enterable gels in a tube. For protection of electrical components from water or dust. These products are already cross linked and do not harden. They are non-toxic, have no shelf life and fit any standard cartridge gun.
• Non toxic, no shelf life
• Re-enterable and reusable even after long periods of operation
• Self amalgamating characteristics
• Gives protection greater than IP68 according to IEC 529
• Dielectric strength >23 Kv/mm
• Volume resistivity >2.1015Ω cm
• Working temperature: -60°C to + 200°C
• Overload temperature for short periods up to +250°C
• Fungal and UV stabilized
Bravo and Mini Bravo Gel Connectors
Pre-filled gel boxes with integrated connectors and designed to fit inside enclosures to get complete protection from water or dust, even in low IP rated enclosures.
Mini Bravo
Extra flat pre-filled gel boxes with connectors designed to fit inside enclosures to get complete protection from water or dust, even in low IP rated enclosures.
• Re-enterable and reusable
• No shelf life and completely non-toxic
• Fully submersible
• Can be used underground
• Installation temperature -40°C to + 50°C Approvals:
• IPX8 - officially tested by IMQ
Ray Gel
Optically clear gel
Two part re-enterable gel potting compound used to protect electrical components from water and dust.
Fully submersible to high depths, completely non-toxic and has no shelf life even after the bottles have been opened.
• 1:1 ratio
• Non toxic, no shelf life and non oily
• Re-enterable even after long periods of operation
• Cross links at less than 10 minutes depending on temperature
• Gives protection greater than IP68 according to IEC 529
• Dielectric strength >23Kv/mm
• Volume resistivity >2.1015Ω cm
• Working temperature for short periods up to +200˚C
• Fungal and UV stabilised
Approvals:
• EN50393: CEI 20-33, fire retardant according to IUEC 322-1 CEI 20-33
       Part No.
Part No.
Max Core Size
Description
Cartridge of Clear Gel
Cartridge Clear Gel (Budget Tube with no External Box Packaging)
Mono Gel
Size
      Wonder Gel
Cartridge of Green/Blue Gel
280ml
   Wonder Gel Invisible
280ml
   Wonder Fluid 280
Monogel
Cartridge of Green/Blue Gel (Slightly More Fluid than Wonder Gel and No External Box Packaging)
280ml
   300ml
           Dimensions
Pack Size
       Bravo 1-6
1 x 1-6mm2
50 x 29 x 22mm
1
    Bravo 3-6
Mini Bravo 1
3 x 1-6mm2
1 x 1-4mm2
53 x 49 x 22mm
1
    41 x 28 x 19mm
3
    Mini Bravo 2
Mini Bravo 3
2 x 1-4mm2
3 x 1-4mm2
45 x 37 x 24mm
1
    53 x 39 x 24mm
1
       Part No. Description Size
  RAY GEL 300-T
  2 x 150ml Bottles
  300ml
 RAY GEL 1000-T
 2 x 500ml Bottles, Jug + Spatula
 1 ltr
 RAY GEL 10K-T
 2 x 5 Litre Bottles, Jug + Spatula
 10 ltr
    20
