                    CABLE & ACCESSORIES Cable Jointing
Fred and Barney
New Inline Gel Connector IP68
The new inline gel connectors Fred and Barney come complete with integrated relief and strip connectors
    • Re-enterable and reusable
• No shelf life and completely non-toxic
• Fully submersible
• Can be used underground
• Operating temperature +90˚C Approvals:
• IP68 - officially tested by IMQ
Fred-Y-N
Part No. Description Dimension Cable Range Colour Pack Size
  BARNEY
 c/w 2 Core 10 Amp
 75 x 28 x 19mm
 6-10mm
 Grey
 1
 BARNEY-N
 c/w 2 Core 10 Amp
 75 x 28 x 19mm
 6-10mm
 Black
 1
 BARNEY-MP
  c/w 2 Core 10 Amp
  75 x 28 x 19mm
  6-10mm
  Grey
  10
 FRED
c/w 3 Core 10 Amp
80 x 36 x 23mm
8-13mm
Grey
1
 FRED-N
 c/w 3 Core 10 Amp
 80 x 36 x 23mm
 8-13mm
 Black
 1
 FRED-MP
 c/w 3 Core 10 Amp
 80 x 36 x 23mm
 8-13mm
 Grey
 10
 FRED-Y
  c/w 3 Core 32 Amp
  110 x 25 x 72mm
  8-13mm
  Grey
  1
 FRED-Y-N
 c/w 3 Core 32 Amp
 110 x 25 x 72mm
 8-13mm
 Black
 1
   Ready Box IP68
  The new Ready Box IP68 is an enclosure pre-filled with gel in either half that allows simple installation of cables that require protection from water or dust.
The enclosure comes complete with 4 integrated internally (M20) and externally threaded glands. This makes the enclosure truly unique an ideal even if you are using conduit as conduit glands can be screwed directly into the integrated glands.
It can also be buried and accommodate branch connections for SWA cables up to 6mm2.
• Re-enterable and reusable Approvals:
Baby Box
Ready Box 120
 • Halogen free and UV resistant
• Just snap shut
• Non-toxic and no shelf life
• Halogen free and UV resistant
• IP68 – officially test by IMQ
• Glow wire test a +960°C according to
EN 60695-2-11
• Operating temperature +90°C
• Gel operating temperature -60°C to + 200°C
 Part No. Cable Range Dimensions Pack Size Colour
 Baby Box
 6-18mm
 90 x 80 x 47mm
 1
 Grey
 Baby Box-N
6-18mm
90 x 80 x 47mm
1
Black
 Ready Box 90
 6-18mm
 90 x 90 x 45mm
 1
 Grey
 Ready Box 90-N
 6-18mm
 90 x 90 x 45mm
 1
 Black
 Ready Box 120
  6-18mm
  120 x 100 x 50mm
  1
  Grey
 Ready Box 120-N
 6-18mm
 120 x 100 x 50mm
 1
 Black
   King Joints - Straight
Baby Box
  Pre-filled gel IPX8 cable joints for armoured and unarmoured cables complete with unique adjustable slide connector to make installation very quick and easy. For unarmoured cables simply discard the included earth continuity kit
• Re-enterable and reusable Approvals:
• No shelf life and completely non-toxic
• Suitable for permanent submersion in water
or underground
• Di-electric strength >23 Kv/mm
GENERATE VALUE
• CEI EN50393 with connectors complying with EN 61238-1
(with additional testing of pushing water
through the cable cores)
• Class 2 in accordance with CEI 64-8 • IPX8 – officially tested by IMQ
    Part No.
 Range
 Dimensions
 Max O/D
 King Joint L6 ARM
1.5-4mm2 5 Core SWA/1.5- 6mm2 5 Core Flex
105 x 55 x 55mm
20.5mm
 King Joint L10 ARM
  2.5-10mm2 5 Core SWA/FLEX
  180 x 60 x 60mm
  24mm
 King Joint L25 ARM
 4-25mm2 5 Core SWA/FLEX
 210 x 65 x 65mm
 31mm
     Together we
19
