Cable & Accessories28 Together we GENERATE VALUEHappy Line%u2022 No shelf life%u2022 For rigid or flexible insultated wires up to 6mm2%u2022 Ready to use & re-enterable%u2022 Fully submersible & can be used underground%u2022 Halogen-free gel & UV resistant%u2022 IPX8 protectionPart No. Dimensions Through ConnectLever ArmColour Pack SizeHappy 0 41 x 28 x 19mm 2 core 2.5mm%u00b2 3 Arms Orange 4Happy 1 45 x 37 x 24mm 3 core 2.5mm%u00b2 5 Arms Silver 2Happy 2 53 x 39 x 24mm 3 core 4mm%u00b2 6 Arms Yellow 1Super ClikPart No. Description Dimensions Max O/DSuper Clik 0 Up to 3 Core 6mm%u00b2 Flex or 3 Core 4mm%u00b2 and 2.5mm%u00b2 Branch95 x 43 x 28mm 14mmSuper Clik 1 Up to 5 Core 6mm%u00b2 Straight or 5 Core 5mm%u00b2 and 5 Core 2.5mm%u00b2 Branch150 x 56 x 30mm20.5mmSuper Clik 2 Up to 5 Core 16mm%u00b2 Straight or 5 Core 10mm%u00b2 and 5 Core 6mm%u00b2 Branch220 x 85 x 46mm30mmSuper Clik 3 Up to 4 Core 25mm%u00b2 and 4 Core 16mm%u00b2 for the Branch220 x 85 x 46mm30mmSuper Clik Mini L 3 x 0,5 - 1,5 Straight Connectors In Line 71 x 38 x 23mm 10mmSuper Clik Mini Y Branch Connections T: 1 x 2,5 - 6, B: 1 x 2,571 x 38 x 23mm 10mmGel Cover LinePart No. Colour Housed Connectors TypeNo of PiecesDimensions mmOHM White 2 core 4mm%u00b2 1 61 x 35 x 28OHM PACK 11 White 2 core 4mm%u00b2 11 61 x 35 x 28BAR White 3 core 6mm%u00b2 1 63 x 41 x 28BAR PACK 9 White 3 core 6mm%u00b2 9 63 x 41 x 28GEL COVER 4 Green 2 core 4mm%u00b2 1 61 x 35 x 28MAMMUT GEL COVER Green 2 core 4mm%u00b2 8 61 x 35 x 28GEL COVER 6 Green 3 core 6mm%u00b2 1 63 x 41 x 28MAMMUT GEL COVER 6 Green 3 core 6mm%u00b2 6 63 x 41 x 28%u2022 For domestic & industrial use%u2022 Ready to use%u2022 Non toxic%u2022 Halogen-free Gel%u2022 Fully submersible & can be used underground%u2022 UV resistant%u2022 CEI EN 50393%u2022 IPX8Prefilled gel cable joints suitable for unarmoured cables complete with connectors.%u2022 Re-enterable and reusable%u2022 Non-toxic and no shelf life%u2022 Fully submersible & can be used underground%u2022 Halogen-free gel & UV resistant%u2022 No flame Propagation: CEI 20-35/ IEC 60332-1 / HD405-1%u2022 IPX8 protection%u2022 CEI EN 50393Mini pre-filled gel boxes that allow 3 different ways of entry. Small, compact & robust, with safety closure feature.Pre-filled cover for straight connections, for the protection, safety & covering of electrical connectors.Raytech - Waterproof Connections
