                                    472HEATING & VENTILATIONTogether we GENERATE VALUEVentilationMonsoon Radial Ducting• Corrosion proof with an antistatic and antibacterial coating• Duct has a smooth inter surface for minimal resistance• Huge time & cost savings compared to traditional ducting• Robust, quick and easy to install• Crush resistant and double walled for flexibility• Low profile system• Plug and play system ideal for self buildersPart No. DescriptionUNRAD69/50 Radial Ducting Anti-Bacterial 69mm x 50mUNVC69/90 VC70CH 69 Valve Collector 3x Ø69-125 H= 70 90° UNDB69/12/125 TVG 69 125 Distribution Box 12 x Ø69 side connection Spigot Ø125UNDB69/12/160 125 Distribution Box 12 x Ø69 side connection Spigot Ø160UNDB69/8/160 125 Distribution Box 8 x Ø69 side connection Spigot Ø160UNCON69 KS 69 Coupler + 2 Rubber Gaskets Ø69UNSVC69 Straight Radial Collector 3 x 69, x 125mmUNAV125 Adjustable ValveUNQVXL125 Adjustable Valve LargeUNAVSQ125 Adjustable Valve SquareUNAVC125 CollarUNFDD69/12/160 XXXXUNFDD69/18/160 XXXXMonsoon Shuttered Fan Range - 9” & 12” Auto Shutter Fan• Simple installation• External 2 speed reversible on/off controller available• Manufactured impact resistant high gloss ABS for strength and durability• Motor fitted with thermal over load protection• Meets the requirements of Building Regulation Document F• IP44 rated, DEMKO Approved, and CE marked in accordance with all the relevant EEC Harmonised Directives• Double Insulated, class II motor fitted with thermal protectionPart No. DescriptionMON23A 225mm Auto Shutter - 190l/sMON30A 300mm Auto Shutter - 267l/sMON-WK23 230mm Window Kit to SuitMON-WK30 300mm Window Kit to SuitMON-RS23/30 2 Speed Reversible On/Off ControllerNational Ventilation’s radial air distribution system is designed for use in homes, apartments and small buildings. The radial system is up to 60% quicker and easier to install, saving time and money.How It WorksThe Monsoon Radial Ducting comes on a 50-metre roll, giving you the flexibility to cut it to the correct length for the application. The manifold acts as an air distribution hub, each outlet evenly servicing a different room. Twin or single semi-rigid duct runs are securely connected to a plenum positioned in each room, terminating with an air valve or grille.230mm fixed grilled fan suitable for panel/wall mounting or window mounting using the appropriate window accessory kit. Suitable for commercial applications in pubs, hotels, restaurants, offices, schools, shops and factories.
