502HEATING & VENTILATIONTogether we GENERATE VALUEMVHRs - Whole House Ventilation With Heat RecoveryMVHRs UprightPart No. Size Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%WHHR Midi BY 125mm WHHR Midi, Bypass, Universal 101 79 58 36 14 120 69 31 11 2.2 33.9 29.9 26.6 24.6 19.7WHHR Midi LBYH 125mm Midi, Bypass, Left Drain, Humidistat 101 79 58 36 14 120 69 31 11 2.2 33.9 29.9 26.6 24.6 19.7WHHR Midi RBYH 125mm Midi, Bypass, Right Drain, Humidistat 101 79 58 36 14 120 69 31 11 2.2 33.9 29.9 26.6 24.6 19.7Midi BY LCD 125mm Midi, Bypass, Universal, Integral LCD 101 79 58 36 14 120 69 31 11 2.2 33.9 29.9 26.6 24.6 19.7Midi BY+LCDLH 125mm Midi, Bypass, Left Drain, Humidistat, Integral LCD101 79 58 36 14 120 69 31 11 2.2 33.9 29.9 26.6 24.6 19.7Midi BY+LCDRH 125mm Midi, Bypass, Right Drain, Humidistat, Integral LCD101 79 58 36 14 120 69 31 11 2.2 33.9 29.9 26.6 24.6 19.7MIDI MVHR with summer bypass & frost-stat, for properties up to 170m2, up to 94% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.50 W/l/s accurate commissioning via optional integral LCD or remote LCD commissioning unit.Part No. Size Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%WHHRMaxi BY 150mm WHHR Maxi , Bypass Universal 177 138 99 60 23 176 97 44 17 4 38.1 35.9 33.2 24.2 20.2WHHRMaxi/BLH 150mm WHHR Maxi, Bypass, Left Drain, Humidistat 177 138 99 60 23 176 97 44 17 4 38.1 35.9 33.2 24.2 20.2WHHRMaxi/BRH 150mm WHHR Maxi, Bypass, Right Drain, Humidistat 177 138 99 60 23 176 97 44 17 4 38.1 35.9 33.2 24.2 20.2Maxi BY+LCD 150mm Maxi, Bypass, Universal, Integral LCD 177 138 99 60 23 176 97 44 17 4 38.1 35.9 33.2 24.2 20.2Maxi BY+LCDLH 150mm Maxi, Bypass, Left Drain, Humidistat, Integral LCD177 138 99 60 23 176 97 44 17 4 38.1 35.9 33.2 24.2 20.2Maxi BY+LCDRH 150mm Maxi, Bypass,Right Drain, Humidistat, Integral LCD177 138 99 60 23 176 97 44 17 4 38.1 35.9 33.2 24.2 20.2MAXI MVHR with summer bypass & frost-stat, for properties up to 250m2, up to 92% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.40 W/l/s accurate commissioning via optional integral LCD or remote LCD commissioning unit.Part No. Size Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%Maxi PLUS BY 150mm Maxi PLUS, Bypass, Universal 238 186 135 84 35 355 184 85 32 8 43.1 37.4 32.8 26 20.4Maxi Plus/BLH 150mm WHHR Maxi PLUS, Bypass, Left Drain Humidistat 238 186 135 84 35 355 184 85 32 8 43.1 37.4 32.8 26 20.4Maxi Plus /BRH 150mm WHHR Maxi PLUS, Bypass,Right Drain Humidistat 238 186 135 84 35 355 184 85 32 8 43.1 37.4 32.8 26 20.4Maxi Plus BY LCD 150mm Maxi Plus, Bypass, Universal, Integral LCD 238 186 135 84 35 355 184 85 32 8 43.1 37.4 32.8 26 20.4Maxi Plus BLHLCD 150mm Maxi Plus, Bypass, Left Drain, Humidistat, Integral LCD238 186 135 84 35 355 184 85 32 8 43.1 37.4 32.8 26 20.4Maxi Plus BRHLCD150mm Maxi Plus, Bypass, Right Drain, Humidistat, Integral LCD238 186 135 84 35 355 184 85 32 8 43.1 37.4 32.8 26 20.4MAXI PLUS MVHR with summer bypass & frost-stat, for properties up to 400m2, up to 89% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.46 W/l/s accurate commissioning via optional integral LCD or remote LCD commissioning unit.MIDI MAXI MAXI PLUS
