503HEATING & VENTILATIONTogether we GENERATE VALUEMVHRs - Whole House Ventilation With Heat Recovery And Integral Acoustic AttenuationMVHRs Upright ATPart No. Size Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%Midi BY AT 125mm Midi, Bypass, Attenuation, Integral LCD 101 79 58 36 14 120 69 31 11 2.2 34 28 21 15 <10Midi BYAT/LH 125mm Midi, Bypass, Attenulation, Left Drain, Humidistat, Integral LCD101 79 58 36 14 120 69 31 11 2.2 34 28 21 15 <10Midi BYAT/RH 125mm Midi, Bypass, Attenulation, Right Drain, Humidistat, Integral LCD101 79 58 36 14 120 69 31 11 2.2 34 28 21 15 <10MIDI BY-AT- MVHR with INTEGRAL ACOUSTIC ATTENUATION, summer bypass & frost-stat, for properties up to 170m2, up to 94% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.50 W/l/s accurate commissioning via optional integral LCD or remote LCD commissioning unit.Part No. Size Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%Maxi BY-AT 150mm Maxi, Bypass, Attenuation Universal, Integral LCD177 138 99 60 23 176 97 44 17 4 41 38 29 20 <10Maxi BYATH/LH 150mm Maxi, Bypass, Attenuation, Left Drain, Humidistat, Integral LCD177 138 99 60 23 176 97 44 17 4 41 38 29 20 <10Maxi BYATH/RH 150mm Maxi, Bypass, Attenuation, Right Drain, Humidistat, Integral LCD177 138 99 60 23 176 97 44 17 4 41 38 29 20 <10MAXI BY-AT- MVHR with INTEGRAL ACOUSTIC ATTENUATION, summer bypass & frost-stat, for properties up to 250m2, up to 92% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.40 W/l/s accurate commissioning via optional integral LCD or remote LCD commissioning unitPart No. Size Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%MaxiPlus/BYAT 150mm Maxi Plus, Bypass, Attenuation, Universal, Integral LCD238 186 135 84 35 355 184 85 32 8 47 40 37 26 12MaxiPlus/ATHLH 150mm Maxi, Bypass, Attenulation, Left Drain, Humidistat Integral LCD238 186 135 84 35 355 184 85 32 8 47 40 37 26 12MaxiPlus/ATHRH 150mm Maxi, Bypass, Attenulation, Right Drain, Humidistat, Integral LCD238 186 135 84 35 355 184 85 32 8 47 40 37 26 12MAXIPLUS BY-AT- MVHR with INTEGRAL ACOUSTIC ATTENUATION, summer bypass & frost-stat, for properties up to 400m2, up to 89% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.46 W/l/s accurate commissioning via optional integral LCD or remote LCD commissioning unit.MIDI BY-AT MAXI BY-AT MAXI PLUS BY-AT
