504HEATING & VENTILATIONTogether we GENERATE VALUEMVHRs In-lineMVHRs In-linePart No. Size Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%EVO220DC/BALBY 125mm WHHR - Bottom Access, Left Drain, Bypass 75 58 42 26 10 96 52 26 11 5 34 28.9 23.2 16.2 7.9EVO220DC/BARBY 125mm WHHR - Bottom Access, Right Drain, Bypass 75 58 42 26 10 96 52 26 11 5 34 28.9 23.2 16.2 7.9EVO220DC/TALBY 125mm WHHR - Top Access, Left Drain, Bypass 75 58 42 26 10 96 52 26 11 5 34 28.9 23.2 16.2 7.9EVO220DC/TARBY 125mm WHHR - TopAccess, Right Drain, Bypass 75 58 42 26 10 96 52 26 11 5 34 28.9 23.2 16.2 7.9EVO220DC/BALBYH 125mm WHHR - Bottom Access, Left Drain, Bypass, Humidistat 75 58 42 26 10 96 52 26 11 5 34 28.9 23.2 16.2 7.9EVO220DC/BARBYH 125mm WHHR - Bottom Access, Right Drain Bypass, Humidistat 75 58 42 26 10 96 52 26 11 5 34 28.9 23.2 16.2 7.9EVO220DC/TALBYH 125mm WHHR - Top Access, Left Drain, Bypass, Humidistat 75 58 42 26 10 96 52 26 11 5 34 28.9 23.2 16.2 7.9EVO220DC/TARBYH 125mm WHHR - Top Access, Right Drain Bypass, Humidistat 75 58 42 26 10 96 52 26 11 5 34 28.9 23.2 16.2 7.9EVO 220 in-line MVHR with summer bypass & frost-stat, up to 87% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.55 W/l/s accurate commissioning via remote LCD commissioning unitPart No. Size Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%EVO250DC/BABY 204x60mm WHHR - bottom access, bypass 85 67 48 30 12 101 53 23 9 2 33.4 28.7 22.4 14.1 <10.0EVO250DC/BALBYH 204x60mm WHHR - bottom access, left hand, bypass, humidistat 85 67 48 30 12 101 53 23 9 2 33.4 28.7 22.4 14.1 <10.0EVO250DC/BARBYH 204x60mm WHHR - bottom access, right hand, bypass, humidistat 85 67 48 30 12 101 53 23 9 2 33.4 28.7 22.4 14.1 <10.0EVO 250 in-line MVHR for properties up to 150m2, with summer bypass & frost-stat, up to 88% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.70 W/l/s accurate commissioning via remote LCD commissioning unitPart No. Size Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%EVO350DC/BABY 200mm WHHR - bottom access, bypass 116 90 64 38 14 157 83 39 15 4 34.6 30.3 24.3 16.5 <10.0EVO350DC/BALBYH 200mm WHHR - Bottom Access, Left Drain, Bypass, Humidistat 116 90 64 38 14 157 83 39 15 4 34.6 30.3 24.3 16.5 <10.0EVO350DC/BARBYH 200mm WHHR - Bottom Access, Right Drain Bypass, Humidistat 116 90 64 38 14 157 83 39 15 4 34.6 30.3 24.3 16.5 <10.0EVO 350 - in-line MVHR for properties up to 200m2, with summer bypass & frost-stat, up to 88% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.65 W/l/s accurate commissioning via remote LCD commissioning unitPart No. Size Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%Studio LB 125mm Studio, Left Drain, Bypass 59 45 30 17 6 100 57 25 10 2 36.3 31.8 26.1 18.4 <10.0Studio RB 125mm Studio, Right Drain, Bypass 59 45 30 17 6 100 57 25 10 2 36.3 31.8 26.1 18.4 <10.0Studio LBH 125mm Studio, Left Drain, Bypass, Humidistat 59 45 30 17 6 100 57 25 10 2 36.3 31.8 26.1 18.4 <10.0Studio RBH 125mm Studio, Right Drain, Bypass, Humidistat 59 45 30 17 6 100 57 25 10 2 36.3 31.8 26.1 18.4 <10.0Studio L 125mm Studio, Left Drain 59 45 30 17 6 100 57 25 10 2 36.3 31.8 26.1 18.4 <10.0Studio R 125mm Studio, Right Drain 59 45 30 17 6 100 57 25 10 2 36.3 31.8 26.1 18.4 <10.0Studio LH 125mm Studio, Left Drain, Humidistat 59 45 30 17 6 100 57 25 10 2 36.3 31.8 26.1 18.4 <10.0Studio RH 125mm Studio, Right Drain, Humidistat 59 45 30 17 6 100 57 25 10 2 36.3 31.8 26.1 18.4 <10.0Studio in-line MVHR for properties up to 100m2, with summer bypass & frost-stat, up to 80% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.87 W/l/s accurate commissioning via remote LCD commissioning unitPart No. Size Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%WHHR Mini LB 125mm WHHR Mini, Left Drain, Bypass 34 24 15 7 2 83 42 19 7 2 39.3 34.6 28.6 20.7 <10.0WHHR Mini RB 125mm WHHR Mini, Right Drain, Bypass 34 24 15 7 2 83 42 19 7 2 39.3 34.6 28.6 20.7 <10.0WHHR Mini LBH 125mm WHHR Mini, Left Drain, Bypass, Humidistat 34 24 15 7 2 83 42 19 7 2 39.3 34.6 28.6 20.7 <10.0WHHR Mini RBH 125mm WHHR Mini, Right Drain, Bypass, Humidistat 34 24 15 7 2 83 42 19 7 2 39.3 34.6 28.6 20.7 <10.0WHHR Mini L 125mm WHHR Mini Left Drain 34 24 15 7 2 83 42 19 7 2 39.3 34.6 28.6 20.7 <10.0WHHR_Mini R 125mm WHHR Mini, Right Drain 34 24 15 7 2 83 42 19 7 2 39.3 34.6 28.6 20.7 <10.0WHHR Mini LH 125mm WHHR Mini, Left Drain, Humidistat 34 24 15 7 2 83 42 19 7 2 39.3 34.6 28.6 20.7 <10.0WHHR Mini RH 125mm WHHR Mini, Right Drain, Humidistat 34 24 15 7 2 83 42 19 7 2 39.3 34.6 28.6 20.7 <10.0Mini - in-line MVHR for properties up to 70m2, with or without summer bypass & frost-stat, up to 83% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 1.11 W/l/s accurate commissioning via remote LCD commissioning unitEVO 220 EVO 250 EVO 350
