303SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEdeta• Surface mounted, steel enclosure with pressed cover and stylish visor • Populated with 1 x 63A 30mA Type A RCD and 1 x 50A MCB • Raised , removable DIN rail to allow cables to pass underneath • IP2X rating for protection from solid objects larger than 12.5mm • 10 year guarantee • BS7671:2018+A2:2022 Part No. DescriptionPE9110 4 Module IP2X High Integrity Consumer UnitsConsumer Units, Enclosures & DevicesMains Switch Consumer Units• Surface mounted, steel enclosure with pressed cover incorporating lockable visor• Populated with 100A DP mains switch, Type 2 SPD and 2 x 100A 30mA Type A RCDs 11, 15 or 25 free ways• Large oval cable entries on rear, supplied with grommets with multiple cut outs • Raised, removable DIN rail to allow cables to pass underneath • Floating busbar with pre-fitted cover for greater flexibility • Supplied with circuit identification labels sheet and blank modules • Supplied with 3 neutral floating busbars for greater installation flexibilty• 10 year guarantee• BS7671:2018+A2:2022 Part No. DescriptionPE3018S 18 Module, 11 Free WaysPE3022S 22 Module, 15 Free WaysPE3032S 32 Module, 25 Free WaysPart No. DescriptionPE1008S 8 Module, 5 Free WaysPE1010S 10 Module, 7 Free WaysPE1014S 14 Module, 11 Free WaysPE1018S 18 Module, 15 Free WaysPE1022S 22 Module, 19 Free Ways• Surface mounted, steel enclosure with pressed cover incorporating stylish lockable visor• Populated with 100A DP mains switch and Type 2 SPD • 5, 7, 11, 15 or 19 free ways • Large oval cable entries on rear, supplied with grommets with multiple cut outs• Raised , removable DIN rail to allow cables to pass underneath • Floating busbar with pre-fitted cover for greater flexibility • 10 year guarantee • BS7671:2018+A2:2022 Shower EnclosuresGarage Enclosures• Surface mounted, steel enclosure with pressed cover and stylish visor • Populated with 1 x 63A 30mA Type A RCD, 1 x 32A MCB and 1 x 6A MCB• Raised , removable DIN rail to allow cables to pass underneath • IP2X rating for protection from solid objects larger than 12.5mm • 10 year guarantee • BS7671:2018+A2:2022 Part No. DescriptionPE9010 4 Module IP2X RCBOs Type AB CurvePart No.C CurvePart No.DescriptionPD4006 PD4106 6A 30mA RCBO Type APD4010 PD4110 10A 30mA RCBO Type APD4016 PD4116 16A 30mA RCBO Type APD4020 PD4120 20A 30mA RCBO Type APD4025 - 25A 30mA RCBO Type APD4032 PD4132 32A 30mA RCBO Type APD4040 PD4140 40A 30mA RCBO Type A• 1P + SwN, Type A RCD, B or C Curve Residual Current Circuit Breaker with Overload Protection• 30mA tripping current provides protection against earth fault leakage current, short circuit and overloading • 1 module width • 35mm DIN rail mounting • Terminals have an automatic blanking plate preventing incorrect termination• Can be removed without removing the busbar• 5 year guarantee • IEC 61009-1 AFDD/RCBOs Type AB CurvePart No.C CurvePart No.DescriptionPD5006 PD5106 6A AFDD/RCBO Type APD5010 PD5110 10A AFDD/RCBO Type APD5016 PD5116 16A AFDD/RCBO Type APD5020 PD5120 20A AFDD/RCBO Type APD5032 PD5132 32A AFDD/RCBO Type APD5040 PD5140 40A AFDD/RCBO Type A• 1P + SwN Arc Fault Detection Device and combined Type A, B or C Curve, Residual Current Circuit Breaker with Overload Protection• Protection against fires started by serial/parallel arc faults that can not be detected by MCBs, RCBOs or RCDs • 30mA tripping current provides protection against earth fault leakage current, short circuit and overloading • 1 module width • 35mm DIN rail mounting • Terminals have an automatic blanking plate preventing incorrect termination• Can be removed without removing the busbar• 5 year guarantee • IEC/EN 60898-1 & BS EN 62606
