Page 304 - Fegime - Electrical Product Guide Issue 1 V5
P. 304

                    SWITCHGEAR & DISTRIBUTION Distribution
Distribution Boards
MCBs & RCBOs
        Single Pole MCBs - 10kA
BS EN 60898.
Part No. Type B
Part No. Type C
Part No. Type D
Rating
 6HS06B
 6HS06C
 6HS06D
 6A
 6HS10B
  6HS10C
  6HS10D
  10A
 6HS16B
6HS16C
6HS16D
16A
 6HS20B
 6HS20C
 6HS20D
 20A
 6HS25B
 6HS25C
 6HS25D
 25A
 6HS32B
  6HS32C
  6HS32D
  32A
 6HS40B
6HS40C
6HS40D
40A
 6HS50B
  6HS50C
  6HS50D
  50A
 6HS63B
 6HS63C
 6HS63D
 63A
  Loadstar 125A ‘Meter Ready’ Type B Distribution Board Integral Metering option.
Loadstar 125A
Incoming Options
Order device and kit (where required) separately.
 Part No.
Modules
Dimensions HxWxD (mm)
 18LS04MR
 4 Ways
 490 x 430 x 155
 18LS06MR
  6 Ways
  570 x 430 x 155
 18LS08MR
8 Ways
650 x 430 x 155
 18LS12MR
 12 Ways
 815 x 430 x 155
 18LS16MR
 16 Ways
 895 x 430 x 155
 18LS20MR
  20 Ways
  1000 x 430 x 155
 18LS24MR
 24 Ways
 1140 x 430 x 155
  Part No. Device
Part No. Kit
 Switch Disconnector, Modular (50mm2)
 40SW3
 No Kit Required
 TP 40A
 63SW3
TP 63A
 100SW3
 TP100A
 125SW3
 TP125A
 40SW4
 18LK125
 FP 40A
 63SW4
  18LK125
  FP 63A
 100SW4
18LK125
FP 100A
 125SW4
  18LK125
  FP 125A
 100SW2
 18LKTPSP
 DP 100A
(TP to SP Conversion)
 125SW2
 18LKTPSP
 DP 125A
(TP to SP Conversion)
     Triple Pole MCBs - 10kA
BS EN 60898.
Part No. Type B
Part No. Type C
Part No. Type D
Rating
 6HT06B
 6HT06C
 6HT06D
 6A
 6HT10B
 6HT10C
 6HT10D
 10A
 6HT16B
 6HT16C
 6HT16D
 16A
 6HT20B
  6HT20C
  6HT20D
  20A
 6HT25B
6HT25C
6HT25D
25A
 6HT32B
 6HT32C
 6HT32D
 32A
 6HT40B
 6HT40C
 6HT40D
 40A
 6HT50B
  6HT50C
  6HT50D
  50A
 6HT63B
 6HT63C
 6HT63D
 63A
    Accessories
125A Integral Meter Kit
  Part No. Description
    18BP1/6
Blanking Strip -
6 Individual 1 Module Wide
   18BB1
Busbar Cross Connector Insulator
  18MBP1
SP MCB Size Blank
  Integral meter kit suitable for mounting within 125A type B Meter Ready (MR) Distribution Boards* includes a digital energy meter, three current transformers, fuses, wiring looms and mounting base plate.
*Integral meter kits are designed for use in conjunction with modular three pole incoming options only. For other incoming options select the ‘add-on’ assembly.
125A Single Meter Packs
245mm high ‘add on’ assemblies suitable for mounting directly beneath any surface 125A Type B Distribution Board. Includes a digital energy meter, three current transformers and all associated fuses and wiring. Enclosures have a slotted front plate and hinged door with catch offering a lockable option.
RCBOs - Single Module - 10kA
18mm wide, suitable for use within Loadstar Distribution Boards 30mA sensitivity, ‘B’ or ‘C’ characteristic, unswitched Neutral. IEC/EN 61009.
   Part No. Description
  LS125MPKIT
Integral Meter Kit - 125A
  LS125MIDMPKIT
 Part No. Type B
Part No. Type C
Rating
 6HSR06/30B
 6HSR06/30C
 6A
 6HSR10/30B
 6HSR10/30C
 10A
 6HSR16/30B
  6HSR16/30C
  16A
 6HSR20/30B
6HSR20/30C
20A
 6HSR32/30B
 6HSR32/30C
 32A
 6HSR40/30B
  6HSR40/30C
  40A
 6HSR50/30B
 6HSR50/30C
 50A
      Part No. Description
Integral Meter Kit (MID) - 125A
     18ML125 ‘Add-On’ Meter Pack - 125A
  304
