308SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEDistribution BoardsPart No. Description Rating (A)Total no. of 18mm TP Outgoing Ways (63A Max)Total no. of 27mm TP Outgoing Ways (125A Max)Total no. of Outgoing WaysEBM22H 2 Way TPN 20 0 2 2EBM62H 6 Way TPN 25 4 2 6EBM82H 8 Way TPN 25 6 2 8EBM122H 12 Way TPN 25 10 2 12EBM182H 18 Way TPN 25 16 2 18EBM242H 24 Way TPN 25 22 2 24250A TPN, Type B High Load Distribution Board• These boards include 2 TPN outgoing ways for 27mm MCB (upto 125A)• Adequate integral cabling space means that no extension box is required• IP4X• Fitted with door lock as standard• Includes factory fitted 250A switch disconnector and two channel meter• Adequate integral cabling space means that no extension box is required• IP4X• Fitted with door lock as standard• Single phasing kit included to be used if required• MID certified meterPart No. Description Rating (A)Total no. of Outgoing Ways Installed Meter CharacteristicsEBMSL642MID Split Metered TPN 200 6+4 MID Certified Modbus + Pulsed, kWhEBMSL862MID Split Metered TPN 200 8+6 MID Certified Modbus + Pulsed, kWhEBMSL1082MID Split Metered TPN 200 10+8 MID Certified Modbus + Pulsed, kWhEBMSL14102MID Split Metered TPN 200 14+10 MID Certified Modbus + Pulsed, kWhOutgoing Devices, RCBOs Single Pole• Eaton’s range of residual current circuit breakers with integral overload protection (RCBOs), are manufactured to IEC/ EN 61009 and meet the latest European and international standardsPart No. Description Rating (A)Trip Type Sensitivity (mA)EMCH106R30C RCBO 6A 10kA type C SP 6 C 30EMCH110R30C RCBO 10A 10kA type C SP 10 C 30EMCH116R30C RCBO 16A 10kA type C SP 16 C 30EMCH120R30C RCBO 20A 10kA type C SP 20 C 30EMCH125R30C RCBO 25A 10kA type C SP 25 C 30EMCH132R30C RCBO 32A 10kA type C SP 32 C 30EMCH140R30C RCBO 40A 10kA type C SP 40 C 30EMCH145R30C RCBO 45A 10kA type C SP 45 C 30Part No. Description Rating (A)Trip Type Sensitivity (mA)EMBH106R30C RCBO 6A 10kA type B SP 6 B 30EMBH110R30C RCBO 10A 10kA type B SP 10 B 30EMBH116R30C RCBO 16A 10kA type B SP 16 B 30EMBH120R30C RCBO 20A 10kA type B SP 20 B 30EMBH132R30C RCBO 32A 10kA type B SP 32 B 30EMBH140R30C RCBO 40A 10kA type B SP 40 B 30EMBH145R30C RCBO 45A 10kA type B SP 45 B 30RCBOsTrip Type B - 30mA SensitivityTrip Type C - 30mA SensitivitySplit Metered Power And Lighting Board – 230A TPN, Type Beatoneatoneaton
