                    SWITCHGEAR & DISTRIBUTION
Enclosures, Boards & Switches
Modular Enclosures
40CD Range Surface mounting distribution boards and enclosures.
• 2 to 72 modules. • Extractable frame options.
• Wide performance range • All materials are halogen-free
gewiss
 available from IP40 to IP65
• RAL 7035
    IP65 Modular Enclosures Pre-Disposed for Terminal Block
Smoked transparent door, smooth walled enclosure.
IP55 Modular Enclosures Pre-Disposed for Terminal Block
Smoked transparent door, walls with perforation centres.
46 Range Watertight Surface Mounting Distribution & Automation Boards
• The 46QP Range is the ideal solution for the creation of automation and energy distribution boards
• Including monobloc, halogen-free fibreglass loaded polyester enclosure
• RAL 7035
IP66 Watertight Distribution Boards in Polyester
Blank door fitted with lock.
IP40 Modular Enclosures with Door Pre-Disposed for Terminal Block
Walls with perforation centre.
IP65 Modular Enclosures Pre-Disposed for Terminal Block
Smoked transparent door, smooth walled enclosure.
Rotary Isolator Switches
70RT HP Rotary Isolator Switches from 16A to 160A
Rotary isolator switches suitable for surface mounting. Up to IP69. With 2P, 3P, 3P+N and 4P.
2 Pole Rotary Isolator Switches
3 Pole Rotary Isolator Switches
4 Pole Rotary Isolator Switches
Part No.
Modules
Dimensions LxHxD (mm)
Installable Terminal Blocks
Dispersible Power (W)
 GW40101
 4
 143 x 210 x 100
 -
 13
 GW40102
 8
 215 x 210 x 100
 1 x GW40401
 16
 GW40103
  12
  298 x 260 x 140
  1 x GW40402
  26
 GW40106
 18
 410 x 285 x 140
 1 x GW40404
 38
  Part No.
Modules
Dimensions LxHxD (mm)
Installable Terminal Blocks
Dispersible Power (W)
 GW40022
  2
  45 x 130 x 85
  -
  7
 GW40023
4
90 x 130 x 85
-
9
 GW40024
 6
 140 x 155 x 85
 -
 14
 GW40026
 8
 180 x 180 x 95
 1 x GW40401
 18
 GW40028
  12+1
  250 x 215 x 95
  1 x GW40402
  27
 GW40030
 24+2 (2x12)
 250 x 340 x 95
 2 x GW40401
 40
 GW40032
 36+3 (3x12)
 250 x 465 x 95
 2 x GW40402
 54
  Part No.
Modules
Dimensions LxHxD (mm)
Installable Terminal Blocks
Dispersible Power (W)
 GW40001
  4
  105 x 170 x 98
  -
  12
 GW40003
8
180 x 180 x 98
1 x GW40401
13
 GW40005
 12
 250 x 250 x 135
 1 x GW40402
 25
 GW40007
  24 (2x12)
  250 x 375 x 135
  2 x GW40401
  27
 GW40009
 36 (2x18)
 376 x 400 x 135
 2 x GW40402
 41
    Part No.
Terminal Block N mm2
Terminal Block T mm2
Fixing
 GW40401
  (1x25) + (7x10)
  (1x25) + (7x10)
  with screws
 GW40402
 (3x25) + (10x10)
 (3x25) + (10x10)
 with screws
          Part No. Rating Dimensions LxHxD (mm)
  GW70431P
 16A
 125 x 150 x 92.3
 GW70486P
 25A
 125 x 150 x 92.3
 GW70434P
  32A
  125 x 150 x 92.3
 GW70441P
 40A
 125 x 150 x 92.3
   Part No. Rating Dimensions LxHxD (mm)
  GW70432P
 16A
 125 x 150 x 92.3
 GW70487P
  25A
  125 x 150 x 92.3
 GW70435P
32A
125 x 150 x 92.3
 GW70442P
  40A
  125 x 150 x 92.3
 GW70437P
 63A
 156 x 200 x 118.8
   Part No. Modules Dimensions LxHxD (mm) Locks Blank Plates
  GW46001F
 -
 250 x 300 x 160
 1
 GW46401
 GW46002F
 36 (3x12)
 310 x 425 x 160
 2
 GW46402
 GW46003F
 54 (3x18)
 405 x 500 x 200
 2
 GW46403
 GW46004F
  72 (4x18)
  405 x 650 x 200
  2
  GW46404
 GW46005F
96 (4x24)
515 x 650 x 250
2
GW46405
 GW46006F
  140 (5x28)
  585 x 800 x 300
  2
  GW46406
 GW46007F
 180 (5x36)
 800 x 1060 x 350
 2
 GW46407
   Part No. Rating Dimensions LxHxD (mm)
  GW70433P
 16A
 125 x 150 x 92.3
 GW70488P
 25A
 125 x 150 x 92.3
 GW70436P
  32A
  125 x 150 x 92.3
 GW70443P
 40A
 125 x 150 x 92.3
 GW70438P
 63A
 156 x 200 x 118.8
    Part No. Description
  GW46445
  Safety Lock with Handle
 GW46446
 Set of 4 Galvanised Steel Fixing Brackets
