                    SWITCHGEAR & DISTRIBUTION Distribution Equipment & Circuit Protection
Sentinel
  Part No.
sentinel
 • • • •
• •
• •
• • •
High Integrity flexible consumer unit solution 100A main switch pre-wired
Where fitted all RCCBs are Type A
Clearly labelled, top positioned earth & neutral bars
Top, bottom & side knockouts for easy access Retain-screws prevents their loss during installation
Busbars with integrated covers for fingertip protection
Hinged lid with fly lead for safety of earth continuity
Dual RCCB + MCB Fully Loaded
100A main switch
+ 2 80A RCCBs Type A
+ MCBs (6A, 16A, 32A, 40A) + Blanks
SPD Options Available
Dual RCCB Boards
• 100A main switch
• + 2 80A RCCBs Type A • + 2 Blanks
Sentinel Accessories
          Description
europa components
    SLCU16DS
Part No. Description
     SLCUACC01KIT
Accessory Kit
  SLCUNC16280
 SLCUBB-10
Neutral Cable 16mm, 280mm
 100A Busbar, 10 Way
  SLCUBB-14
100A Busbar, 14 Way
   Part No. Description
SLCUBB-18
100A Busbar, 18 Way
     14 (8 useable) Ways
SLCUMMB
Metal Module Covers
  SLCU14DS
  SLCUSPD2KIT
        SLCU16DS-FL01
16 (10 useable) Ways (2x6A, 2x16A, 3x32A, 1x40A) MCBs
SLCU18DS SLCU20DS SLCU24DS-DT
16 (10 useable) Ways
18 (12 useable) Ways 20 (14 useable) Ways 24 (18 useable) Ways
AUSP-40J/1+1
Type 2 SPD Kit w/ 32A MCB & Wires
 1 Mod. Sing. Phase Type 2 for TT/TN SPD
      Sentinel Lockable Lids
   SLCU20DS-FL01
20 (14 useable) Ways (3x6A, 2x16A, 4x32A, 1x40A) MCBs
       SLCU18DS-SPD-FL01
Type 2 SPD
18 (10 useable) Ways (2x6A, 2x16A, 3x32A, 1x40A) MCBs
SLCU36DS-DT
36 (30 useable) Ways
   Compact Garage Unit
• Height: 183mm • Width: 125mm • Depth: 110mm
    SLCU20DS-SPD-FL01
Type 2 SPD
20 (12 useable) Ways (3x6A, 2x16A, 4x32A, 1x40A) MCBs
     Part No. Description
  • •
Main Switch Boards
100A main switch incomer + 2 Blanks
    SLCU6LL
Lockable lid for 6 way board
   SLCU8LL
Lockable lid for 8 way board
  SLCU10LL
Lockable lid for 10 way board
  SLCU12LL
Lockable lid for 12 way board
  SLCU14LL
Lockable lid for 14 way board
  SLCU16LL
Lockable lid for 16 way board
  SLCU18LL
 SLCU20LL
Lockable lid for 18 way board
 Lockable lid for 20 way board
   Part No. Description
    GRGC16M 63A RCCB Type A + 6A & 16A MCB
Part No. Description
  SLCU6M
 6 (4 useable) Ways
 SLCU8M
 8 (6 useable) Ways
 SLCU10M
 10 (8 useable) Ways
 SLCU12M
  12 (10 useable) Ways
 SLCU14M
 14 (12 useable) Ways
 SLCU20M
 20 (18 useable) Ways
     Sentinel boards are for use with our 6kA MCBS (EUB1*B) & compact 6kA RCBOs (EUB1RC) | See the next page for part numbers
