                     SWITCHGEAR & DISTRIBUTION Surge Protection
  Metal Clad Enclosures (IP40)
• Modular Metal Clad Enclosures
• Amendment 3 Compliant Enclosures
• Complete with Earth Terminal & Din Rail
Mersen Surge Protection
• Suitable for TT, TN-S & TN-C-S (PME)
• Din rail mountable, plug-in format
• Visual & remote end of life indicators
• Reversible chassis for entry from above or
below
• Mechanicallycoded
cartridges avoid replacement errors
Enclosed Surge Protection
            • * MEC4T suitable for consumer unit tails
• IP54 metal enclosure • Retrofit solution
• Ideal for any brand of
consumer unit
Part No.
ECSS-101 ECSS-102
Part No.
MEC2M MEC3M MEC4M MEC6M MEC4T
Description
2 Module H: 146 W: 80 D: 62 3 Module H: 105 W: 105 D: 78 4 Module H: 238 W: 125 D: 78 6 Module H: 248 W: 161 D: 78 * 4 Module H: 190 W: 115 D: 61
Part No.
83120115 83120139 83020117 83020147 83230511 83230129
Description
2 Module Type 1/2 single phase TT/TN 4 Module Type 1/2 three phase TT/TN 2 Module Type 2 single phase TT/TN 4 Module Type 2 three phase TT/TN 2 Module Type 2 & 3 single phase TT/TN 4 Module Type 2 & 3 three phase TT/TN
Description
With TT/TN type 2 SPD + 2P main switch With TT/TN type 2 SPD & 32A MCB
   Enclosed Surge Protection
  Metal Clad Garage Units (IP54)
• RAL 7035
• EN 60898 & EN 61008
compliant
• All MCBs are single pole B
curve 6kA
• Earth & neutral terminals
Dehn Surge Protection
• For lightning protection systems with lightning protection levels 3 or 4 up to 12.5kA or for an overhead supply line
• For domestic, commercial & light industrial applications typically up to 125A
• Retrofit solution (with DEHN SPD)
• Ideal for any brand of consumer unit
ECSS-301D
IP65 ABS Enclosure
Part No.
ECSS-301D ECSS-302D
        included
• Dimensions: H: 240 x
W: 160 x D: 85mm
Part No.
GRG16M GRG32M
Description
Part No.
941110 941310 951115 951310 952110 952315
Description
2 Module Type 1/2 Single Phase TT/TN 4 Module Type 1/2 Three Phase TT/TN 4 Module Type 1/2 Single Phase TT/TN 8 Module Type 1/2 Three Phase TT/TN 2 Module Type 2 Single Phase TT/TN
4 Module Type 2 Three Phase TT/TN
ECSS-302D
IP54 Metal Enclosure
Description
TT/TN 3 Phase Type 2 SPD W/ 63A MCB TT/TN 3 Phase Type 2 SPD W/ 63A MCB
    63A RCCB + 6A & 16A MCB 63A RCCB + 6A & 32A MCB
Enclosed Surge Prote
 100A Metal Clad Switch Fuses (IP54)
• 100A 230V single phase switch fuse
• 5 module metal clad enclosure
• Incoming terminal capacity 2.5 to 25mm2
• 4 x M20, 2 x 25mm cable entries
• Free pack of 3 fuses included
• IP67 enclosure
• Retrofit solution
• Idealforanybrandof
consumer unit
ECSS-3101D | DEHN SPD
       310
Together we
100A Switch Fuse
ction
ECSS-3101M | Mersen SPD
surge safe
  Part No.
Description
 ECSS-3101D
  TT/TN 3 Phase Type 1/2 SPD + 160A Fuses
 ECSS-3101M
 TT/TN 3 Phase Type 1/2 SPD + 160A Fuses
     Part No.
SPSF100M-F
Description
