                                    357SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEWiring Devices%u2022 Manufactured and tested to BS EN 61009 10kA breaking capacity%u2022 Let through energy classification of 3 (lowest let through energy best cable protection classification)%u2022 Positive contact indication (guaranteed on/off indication) Trip free MCB mechanism%u2022 Automatic trip on loss of neutral%u2022 Automatic protection against reverse polarity Type C tripping characteristics (5ln to 10ln) 6 - 45A; 10, 30 & 100mA sensitivities%u2022 AC class sensitivity%u2022 For use in LoadCentre A and B boards%u2022 One single pole way occupied in a distribution board Cable capacity 16mm2%u2022 Speed of connection of plug on devices%u2022 Assured system integrity, no other devices fit KQ boardsiKQ RCBO%u2019sPart No. DescriptionSEBLKITT2* Three phase KQ SPD KitSE17BES KQ B board extensionCode Sensivity 30mA RatingSEE106C03 6A 10kASEE110C03 10A 10kASEE116C03 16A 10kASEE120C03 20A 10kASEE125C03 25A 10kASEE132C03 32A 10kASEE140C03 40A 10kASEE145C03 45A 10kA%u2022 SE17BES extension box suggested for fitting of SPD kitSPD KitWiring DevicesPart No. Description RatingEZ9S16291 DP Switch Isolator 100AEZ9R46291 DP Type A RCD 100A 30mAPart No. Rating Type KitEZ9L33620 20kA 2 NoEZ9L33620KIT 20kA 2 YesPart No. Rating Poles CurveEZ9TDA7606 6A 6kA - 30mA 1P+N BEZ9TDA7610 10A 6kA - 30mA 1P+N BEZ9TDA7616 16A 6kA - 30mA 1P+N BEZ9TDA7620 20A 6kA - 30mA 1P+N BEZ9TDA7632 32A 6kA - 30mA 1P+N BEZ9TDA7640 40A 6kA - 30mA 1P+N BPart No. RatingEZ9D16806 6A 6kA 30mAEZ9D16810 10A 6kA 30mAEZ9D16816 16A 6kA 30mAEZ9D16820 20A 6kA 30mAEZ9D16832 32A 6kA 30mAEZ9D16840 40A 6kA 30mAEZ9D16850 50A 6kA 30mAPart No. B Curve Part No. C Curve MCB RatingEZ9F16103 - 3A 6kAEZ9F16106 EZ9F66106 6A 6kAEZ9F16110 EZ9F66110 10A 6kAEZ9F16116 EZ9F66116 16A 6kAEZ9F16120 EZ9F66120 20A 6kAEZ9F16132 EZ9F66132 32A 6kAEZ9F16140 EZ9F66140 40A 6kAEZ9F16150 EZ9F66150 50A 6kAAFDDsRCBOsMCBsIncoming DevicesSPDs
