355SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUE• Manufactured and tested to BS EN 61009 10kA breaking capacity• Let through energy classification of 3 (lowest let through energy best cable protection classification)• Positive contact indication. (guaranteed on/off indication) Trip free MCB mechanism• Automatic trip on loss of neutral• Automatic protection against reverse polarity Type C tripping characteristics (5ln to 10ln) 6 - 45A; 10, 30 & 100mA sensitivities• AC class sensitivity• For use in LoadCentre A and B boards• One single pole way occupied in a distribution board Cable capacity 16mm2• Speed of connection of plug on devices• Assured system integrity, no other devices fit KQ boardsHeavy duty fuse products for use in commercial and industrial environments, providing isolation and traditional fuse protection for electrical loads.TwinbreakHeavy duty fuse products for use in commercial and industrial environments, providing isolation and traditional fuse protection for electrical loads.• Rated for 240/415V 50/60Hz.• Ratings 20A, 32A, 63A, 100A, SP&SwN, TP&N.• Utilisation category AC20A, AC21A, AC22A, AC23B at rated current.• Degree of protection IP41.• Handle position provides positive contact indication.• Door handle prevents door being opened when switch is ON or padlocked.• Handle padlockable in ON and OFF positions.• Fuse links supplied as standard.Distribution BoardsSwitch FusesTwinbreak Switch DisconnectorsPart No. SPSN Part No. TPN RatingSD202SW SD203SW 20ASD322SW SD323SW 32ASD632SW SD633SW 63ASD1002SW SD1003SW 100A - SD1253SW 125A - SD1603SW 160ATwinbreak Switch FusesPart No. SPSN Part No. TPN RatingSD202SFK SD203SFK 20ASD322SFK SD323SFK 32ASD632SFK SD633SFK 63ASD1002SFK SD1003SFK 100AQuadbreakQuadbreak Switch DisconnectorsCode SPSN Code TPN Recommended Cable Entry Box RatingSQB0632L SQB0633L SQBX100 63ASQB1002L SQB1003L SQBX100 100ASQB1602L SQB1603L SQBX160 160ASQB2502L SQB2503L SQBX250 250A - SQB4003L SQBX500 400A - SQB5003L SQBX500 500A - SQB6303L SQBX630 630A - SQB8003L SQBX630 800AHeavy duty fuse products for use in commercial and industrial environments, providing isolation and traditional fuse protection for electrical loads.• Rated for 240/415V 50/60Hz.• Ratings 100A, 160A, 200A, 250A, 315A, 400A, 500A, 630A TP&N.• Utilisation category AC20A, AC21A, AC22A, AC23B at rated current, AC23A for ratings up to 160A.• Handle position provides positive contact indication.• Door handle prevents door being opened when switch is ON or padlocked.• Handle padlockable in ON and OFF positions.• Device may be fed to either top or bottom terminals.• Fuse links or copper links supplied as standard.Quadbreak Switch FusesCode SPSN Code TPN Recommended Cable Entry Box RatingSQB0632K SQB0633K SQBX100 63ASQB1002K SQB1003K SQBX100 100ASQB1602K SQB1603K SQBX160 160ASQB2002K SQB2003K SQBX250 200ASQB2502K SQB2503K SQBX250 250A - SQB3153K SQBX500 315A - SQB4003K SQBX500 400A - SQB5003K SQBX500 500A - SQB6303K SQBX630 630ACode Sensivity 30mA RatingSEE106C03 6A 10kASEE110C03 10A 10kASEE116C03 16A 10kASEE120C03 20A 10kASEE125C03 25A 10kASEE132C03 32A 10kASEE140C03 40A 10kASEE145C03 45A 10kAiKQ RCBO’s
