                                    349INDUSTRIAL CONTROLSTogether we GENERATE VALUESchneider• Class 10A differential Bi-metallic thermal overload relayOverload RelaysContactors & OverloadsPart No. For Use with Contactor LC1 Settings Range AmpsLRD05 D09 ... D38 0.63 ... 1.0LRD06 D09 ... D38 1.0 ... 1.7LRD07 D09 ... D38 1.6 ... 2.5LRD08 D09 ... D38 2.5 ... 4.0LRD10 D09 ... D38 4.0 ... 6.3LRD12 D09 ... D38 5.5 ... 8.0LRD14 D09 ... D38 7.0 ... 10.0LRD16 D12 ... D38 9.0 ... 13.0LRD21 D18 ... D38 12.0 ... 18.0LRD22 D25 ... D38 16.0 ... 24.0LRD32 D12 ... D38 23.0 ... 32.0LRD35 D32 + D38 30.0 ... 38.0LRD340 D40A ... D65A 30.0 ... 40.0LRD350 D40A ... D65A 37.0 ... 50.0LRD365 D50A ... D65A 48.0 ... 65.0LRD3322 D80 + D95 17.0 ... 25.0LRD3353 D80 + D95 23.0 ... 32.0LRD3355 D80 + D95 30.0 ... 40.0LRD3357 D80 + D95 37.0 ... 50.0LRD3359 D80 + D95 48.0 ... 65.0LRD3361 D80 + D95 55.0 ... 70.0LRD3363 D80 + D95 63.0 ... 80.0LRD3365 D80 + D95 80.0 ... 104.0TeSys Model DPart No. Settings Range AmpsLR2K0303 0.23 ... 0.36LR2K0304 0.36 ... 0.54LR2K03058 0.54 ... 0.8LR2K0306 0.8 ... 1.2LR2K0307 1.2 ... 1.8LR2K0308 1.8 ... 2.6LR2K0310 2.6 ... 65.0LR2K0312 3.7 ... 70.0LR2K0314 5.5 ... 80.0LR2K0316 8.0 ... 104.0TeSys Model K• Class 10A differential Bi-metallic thermal overload relayPart No. ContactsLAD7B106 LRD01 ... LRD35LAD73064 LRD33**LRD Accessories• Seperate Mounting Base for overload relaysContactorsTeSys Model K ContactorsPart No. 3Ph/400V (kW)AC-3 (A)AuxiliaryNO NCLC1K0601** 2.2 6 - 1LC1K0610** 2.2 6 1 -LC1K0901** 4 9 - 1LC1K0910** 4 9 1 -LC1K1201** 5.5 12 - 1LC1K1210** 5.5 12 1 -Part No. ContactsLA1KN11 1 NO + 1 NCLA1KN20 2 NOLA1KN22 2 NO + 2 NCPart No. 3Ph/400V (kW)AC-3 (A)AuxiliaryNO NCLC1D09** 4 9 1 1LC1D12** 5.5 12 1 1LC1D18** 7.5 18 1 1LC1D25** 11 25 1 1LC1D32** 15 32 1 1LC1D38** 18.5 38 1 1LC1D40A 18.5 40 1 1LC1D50A 22 50 1 1LC1D65A 30 65 1 1LC1D80** 37 80 1 1LC1D95** 45 95 1 1LC1D115** 55 115 1 1LC1D150** 75 150 1 1Part No. ContactsLADN01 1 NCLADN10 1 NOLADN22 2 NO + 2 NCLADN40 4 NOLADN04 4 NCK-Range Auxillary BlocksTeSys Model D ContactorsD-Range Auxillary Blocks• 3 Pole 6-12A/AC3 (Control coils included)• See table below for AC coil or DC coil suffix• 3 Pole 9-150A/AC3 (Control coils included)• See table below for AC coil or DC coil suffixCoil Ref (Last 2 Digits) 12 24 42 48 110 230 380 400AC Supply J7 B7 C7 E7 F7 P7 Q7 V7DC Supply JD BD FDCoil Voltages - Add the suffix below to the contactor reference to specify control voltage required
