OsiSense Sensors & Leads
OsiSense XS - Inductive Proximity Sensors
Cable Leads
     • Available everywhere at your Telemecanique sensors distributor next door, compliant with international standards & certifications in standard and increased range.
• Our OsiSense XS range is suitable on many applications such as Assembly machines, robotics, machine-tools, machining, packaging, materials handling, conveying, food and beverage industry, etc.
Standard Range
• Telemecanique Sensors offer a full range of connection accessories. • When used with OsiSense sensors these accessories must not only
withstand the same electrical and mechanical stresses but, above all, the same environmental conditions. Products with high mechanical and chemical performance, recommended for all industrial applications.
• The composition of their insulating sheaths means that these cables do not give off halogen or produce corrosive or toxic gases
• The range covers PVC cables, recommended for machines subject
only to moderate mechanical stress; PUR cable for severe industrial environments, halogen free, UL certified and with high degrees of protection, with or without LED, and even reinforced cables with 316L connectors for harsh environments
PUR Cables and Connection - M12 Connection
Part No. Description Connection Sn (mm)
 XS508B1PAL2*
 PNP Output - N/OM8 Short Barel
 2m Cable
 1.5
 XS508B1PAM8
M8 Plug-in
1.5
 XS508BLPAL2
PNP Output - N/OM8 Long Barel
  2m Cable
 1.5
 XS508BLPAM12
 M12 Plug-in
 1.5
 XS512B1PAL2
 PNP Output - N/OM12 Short Barel
 2m Cable
  2
 XS512B1PAM12
M12 Plug-in
2
 XS512BLPAL2
 PNP Output - N/OM12 Long Barel
 2m Cable
 2
 XS512BLPAM12
 M12 Plug-in
 2
 XS518B1PAL2
 PNP Output - N/OM18 Short Barel
  2m Cable
 5
 XS518B1PAM12
  M12 Plug-in
  5
 XS518BLPAL2
PNP Output - N/OM18 Long Barel
2m Cable
5
 XS518BLPAM12
 M12 Plug-in
 5
 XS530B1PAL2
  PNP Output - N/OM30 Short Barel
  2m Cable
  10
 XS530B1PAM12
M12 Plug-in
10
 XS530BLPAL2
 PNP Output - N/OM30 Long Barel
  2m Cable
  10
 XS530BLPAM12
 M12 Plug-in
 10
   Part No. Description Connection
 XZCP0566L2
 Pre-wired M8 Connector - Straight
 2m Cable - 3 Pin
 XZCP0566L5
5m Cable - 3 Pin
 XZCP0666L2
Pre-wired M8 Connector - Elbowed
  2m Cable - 3 Pin
 XZCP0666L5
  5m Cable - 3 Pin
 XZCP1141L2
Pre-wired M12 Connector - Straight
 2m Cable - 4 Pin
 XZCP1141L5
 5m Cable - 4 Pin
 XZCP1241L2
 Pre-wired M12 Connector - Elbowed
  2m Cable - 4 Pin
 XZCP1241L5
 5m Cable - 4 Pin
   Cylindrical - Increased Range - 10 - 36V DC - 3 Wire
PVC Cables and Connection - M12 Connection
Part No. Description Connection
 XZCPV0566L2
 Pre-wired M8 Connector - Straight
 2m Cable - 3 Pin
 XZCPV0566L5
5m Cable - 3 Pin
 XZCPV0666L2
Pre-wired M8 Connector - Elbowed
  2m Cable - 3 Pin
 XZCPV0666L5
  5m Cable - 3 Pin
 XZCPV1141L2
Pre-wired M12 Connector - Straight
 2m Cable - 4 Pin
 XZCPV1141L5
 5m Cable - 4 Pin
 XZCPV1241L2
 Pre-wired M12 Connector - Elbowed
  2m Cable - 4 Pin
 XZCPV1241L5
 5m Cable - 4 Pin
  Part No. Description Connection Sn (mm)
    XS108B3PAL2
XS108B3PAM8
  XS608B1PAL2
XS608B1PAM12
  XS118B3PAL2
XS118B3PAM12
Fixing Clamps
PNP Output - N/OM8 Short Barel
PNP Output - N/OM8 Long Barel
PNP Output - N/OM18 Short Barel
2m Cable
2m Cable
2m Cable
2.5
   M8 Plug-in
2.5
  2.5
   M12 Plug-in
2.5
    XS112B3PAL2
PNP Output - N/OM12 Short Barel
2m Cable
4
   XS112B3PAM12
M12 Plug-in
4
    XS612B1PAL2
XS612B1PAM12
PNP Output - N/OM12 Long Barel
2m Cable
4
   M12 Plug-in
4
  8
   M12 Plug-in
8
    XS618B1PAL2
PNP Output - N/OM18 Long Barel
2m Cable
8
   XS618B1PAM12
M12 Plug-in
8
    XS130B3PAL2
PNP Output - N/OM30 Short Barel
2m Cable
15
   XS130B3PAM12
M12 Plug-in
15
    XS630B1PAL2
XS630B1PAM12
PNP Output - N/OM30 Long Barel
2m Cable
M12 Plug-in
15
   15
    Part No. Description Supply
   XSZB108
M8 Fixing Clamp
 M12 Fixing Clamp
M8 Bracket
  XSZB112
M12 Bracket
   XSZB118
XSZB130
M18 Fixing Clamp
M30 Fixing Clamp
M18 Bracket
   M30 Bracket
