343SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEFusesCompact Dimension Fuse-Links Type CDSPart No. Current Rating (A)BS88 ReferenceVoltage Rating(V)Breaking Capacity (kA)Overall Length(mm) (ins)SS2 2 E1 240V A.C. 20kA A.C. 51 2SS4 4 E1 240V A.C. 20kA A.C. 51 2SS6 6 E1 240V A.C. 20kA A.C. 51 2SS10 10 E1 240V A.C. 20kA A.C. 51 2SS16 16 E1 240V A.C. 20kA A.C. 51 2SS20 20 E1 240V A.C. 20kA A.C. 51 2SS25 25 E1 240V A.C. 20kA A.C. 51 2SS32 32 E1 240V A.C. 20kA A.C. 51 2• Lawson type CDS Compact Dimension Fuse-Links are for use in single or three phase commercial or industrial installations and can be fitted into Clipfit Fuse-Holders or suitable distribution fusegear• The Lawson CLIPFIT range has rated voltages of 240V A.C. or 415V A.C. and has been certified at a test recovery voltage of at least 110#0/240 & 400/415 Volt Compact Dimension Fuse-Links to IEC 60269-2/BS 88-2Rated Voltages 240V & 415V A.C. Breaking Capacity 20kA at 240V, 80kA at 415V. Breaking Range and Utilisation Category gGPart No. Current Rating (A)BS88 ReferenceVoltage Rating(V)Breaking Capacity (kA)Overall Length(mm) (ins)NS2 2 F1 415V A.C. 80kA A.C. 62 2 7/16NS4 4 F1 415V A.C. 80kA A.C. 62 2 7/16NS6 6 F1 415V A.C. 80kA A.C. 62 2 7/16NS10 10 F1 415V A.C. 80kA A.C. 62 2 7/16NS16 16 F1 415V A.C. 80kA A.C. 62 2 7/16NS20 20 F1 415V A.C. 80kA A.C. 62 2 7/16NS25 25 F1 415V A.C. 80kA A.C. 62 2 7/16NS32 32 F1 415V A.C. 80kA A.C. 62 2 7/16NS20M25 20.25 F1 415V A.C. 80kA A.C. 62 2 7/16NS20M32 20.32 F1 415V A.C. 80kA A.C. 62 2 7/16NS20M40 32.40 F1 415V A.C. 80kA A.C. 62 2 7/16NS20M50 32.50 F1 415V A.C. 80kA A.C. 62 2 7/16NS20M63 32.63 F1 415V A.C. 80kA A.C. 62 2 7/16Part No. Current Rating (A)BS88 ReferenceVoltage Rating(V)Breaking Capacity (kA)Overall Length(mm) (ins)MES10 10 F2 415V A.C. 80kA A.C. 69 2 11/16MES16 16 F2 415V A.C. 80kA A.C. 69 2 11/16MES20 20 F2 415V A.C. 80kA A.C. 69 2 11/16MES25 25 F2 415V A.C. 80kA A.C. 69 2 11/16MES32 32 F2 415V A.C. 80kA A.C. 69 2 11/16MES40 40 F2 415V A.C. 80kA A.C. 69 2 11/16MES50 50 F2 415V A.C. 80kA A.C. 69 2 11/16MES63 63 F2 415V A.C. 80kA A.C. 69 2 11/16
