P. 342

                    INDUSTRIAL CONTROLS Industrial Control
TeSys GV2 Motor Circuit Breakers
 GV2ME Thermal Magnetic Circuit Breakers
GV2P Thermal Magnetic Circuit Breakers
Part No. 400/415V (kW) Current Settings
 GV2ME01
 -
 0.1 - 0.16
 GV2ME02
0.06
0.16 - 0.25
 GV2ME03
  0.09
  0.25 - 0.4
 GV2ME04
0.12
0.4 - 0.63
 GV2ME05
 0.25
 0.63 - 1.0
 GV2ME06
 0.55
 1.0 - 1.6
 GV2ME07
  0.75
  1.6 - 2.5
 GV2ME08
1.1
2.5 - 4.0
 GV2ME10
 2.2
 4.0 - 6.3
 GV2ME14
 3.0
 6.0 - 10.0
 GV2ME14
 4.0
 6.0 - 10.0
 GV2ME16
  5.5
  9.0 - 14.0
 GV2ME20
7.5
13.0 - 18.0
 GV2ME21
 9.0
 17.0 - 23.0
 GV2ME22
  11.0
  20.0 - 25.0
 GV2ME32
 15.0
 24.0 - 32.0
  Part No. 400/415V (kW) Current Settings
 GV2P01
 -
 0.1 - 0.16
 GV2P02
0.06
0.16 - 0.25
 GV2P03
  0.09
  0.25 - 0.4
 GV2P04
0.12
0.4 - 0.63
 GV2P05
 0.25
 0.63 - 1.0
 GV2P06
 0.55
 1.0 - 1.6
 GV2P07
  0.75
  1.6 - 2.5
 GV2P08
1.1
2.5 - 4.0
 GV2P10
 2.2
 4.0 - 6.3
 GV2P14
 3.0
 6.0 - 10.0
 GV2P20
 7.5
 13.0 - 18.0
 GV2P21
  9.0
  17.0 - 23.0
 GV2P22
11.0
20.0 - 25.0
 GV2P32
 15.0
 24.0 - 32.0
 GV3P40
 18.5
 30.0 - 40.0
 GV3P50
  22.0
  37.0 - 50.0
 GV3P65
 30.0
 48.0 - 65.0
     5.5
DOL Starters
12
110V
F7
F7
4 (Metal)
230V
P7
GV2M GV2P GV2 Auxilliary Blocks
E
Part No.
Types of Contacts
Position
Maximum No. Possible
 GVAE1
 1 NO or 1 NC (rev)
 Front
 1
 GVAE11
 1 NO & 1 NC
 Front
 1
 GVAN11
  1 NO & 1 NC
  Side (LH)
  2
 GVAN20
 1 NO & 1 NC
 Side (LH)
 2
   TeSys Model D
• IP65 DOL Polycarbonate Non-Reversing Starters
Thermal Overload LRD** must be ordered separately.
Pilot Devices - Harm
Complete Pushbuttons & Switches with Chromium Plated Metal Bezel
IP65 Emergency Stop Stations
• Grey base with yellow lid
    Part No.
3Ph/400V (kW)
AC-3 (A)
Standard Voltages
Part No. Description Contact
    400V
    XALK178
1 Red Mushroom Head Pushbutton 40mm dia Latching Twist to Release
      LE1D09**
4
9
V7
1 Red Mushroom Head Pushbutton 40mm dia Latching Turn Key to Release
1 NC
   XALK188
1 NC
      LE1D12**
P7
V7
      LE1D18**
7.5
18
F7
P7
V7
         LE1D25**
11
25
ony Style
F7
P7
V7
      LE1D35**
15
35
F7
P7
V7
        Pilot Lights with Metal Bezel
   Part No. Description NO NC
 Part No. Description
  XB4BVM1
 (ZB4BVM1 + ZB4BV013) White 230V AC LED Pilot Light
 XB4BVM3
  (ZB4BVM3 + ZB4BV033) Green 230V AC LED Pilot Light
 XB4BVM4
(ZB4BVM4 + ZB4BV043) Red 230V AC LED Pilot Light
 XB4BVM5
 (ZB4BVM5 + ZB4BV053) Orange 230V AC LED Pilot Light
 XB4BVM6
 (ZB4BVM6 + ZB4BV063) Blue 230V AC LED Pilot Light
 XB4BVB1
  (ZB4BVB1 + ZB4BV013) White 24V AC/DC LED Pilot Light
 XB4BVB3
(ZB4BVB3 + ZB4BV033) Green 24V AC/DC LED Pilot Light
 XB4BVB4
 (ZB4BVB4 + ZB4BV043) Red 24V AC/DC LED Pilot Light
 XB4BVB5
 (ZB4BVB5 + ZB4BV053) Orange 24V AC/DC LED Pilot Light
 XB4BV61
  (ZB4BV6 + ZB4BV01) White Direct Supply AC BA9 Pilot Light
 XB4BV63
(ZB4BV6 + ZB4BV03) Green Direct Supply AC BA9 Pilot Light
 XB4BV64
  (ZB4BV6 + ZB4BV04) Red Direct Supply AC BA9 Pilot Light
 XB4BV65
 (ZB4BV6 + ZB4BV05) Orange Direct Supply AC BA9 Pilot Light
      XB4BA21
(ZB4BZ101 + ZB4BA2) Black Pushbutton Head
1
-
  XB4BA31
(ZB4BZ101 + ZB4BA3) Green Pushbutton Head
1
-
  XB4BA42
XB4BA51
(ZB4BZ102 + ZB4BA4) Red Pushbutton Head
(ZB4BZ101 + ZB4BA5) Orange Pushbutton Head
-
1
1
  -
  XB4BA61
(ZB4BZ101 + ZB4BA6) Blue Pushbutton Head
(ZB4BZ101 + ZB4BD2) 2 Position Stay Put Selector Switch
1
1
1
-
  XB4BD21
-
  XB4BD25
 XB4BD33
(ZB4BZ105 + ZB4BD2) 2 Position Stay Put Selector Switch
(ZB4BZ103 + ZB4BD3) 3 Position Stay Put Selector Switch
1
2
1
 -
  XB4BG21
(ZB4BZ101 + ZB4BG4) 2 Position Stay Put Key Switch
-
  XB4BP31
(ZB4BZ101 + ZB4BP3) Green Pushbutton with Silicone Boot
1
-
  XB4BP42
(ZB4BZ102 + ZB4BP4) Red Pushbutton with Silicone Boot
-
1
  XB4BS9442
XB4BS8442
(ZB4BZ102 + ZB4BS944) Key Release 40mm E Stop
(ZB4BZ102 + ZB4BS844) Twist Release 40mm E Stop
-
-
1
  1
   342
