339SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEimo stagMotor Control GearIPX8 Waterproof Gel Boxes%u2022 For sealing, protecting electrical connectionsIP40 Buzzers%u2022 Intermittent buzzers with optional red LEDStaircase Time Switch%u2022 Mechanical daily timer with countdownMechanical Time Switch%u2022 General purpose timer with 3 day battery backupDigital Time Switches%u2022 Featuring daily, weekly & random programsScrewless Push/Pull Connectors%u2022 For quick and easy electrical connectionsScrewless Lever Connectors%u2022 For quick and easy electrical connectionsIP68 Waterproof Connectors%u2022 PA66 connectors in straight or %u201cT%u201d typeIP68 Cable Glands%u2022 Complete with Lock Nut & Rubber WasherIP67 LED Pilot Lights%u2022 22.5mm single hole mountingPart No. No. of Wiring EntrancesDimensions (h x w x d)ColourSGB-01 3 45 x 28 x 19mm OrangeSGB-02 3 45 x 37 x 24mm BlueSGB-03 3 53 x 39 x 24mm YellowPart No. Description Voltage RatingBZR-24 Buzzer 24VAC/DCBZRL-24 Buzzer with Red LED 24VAC/DCBZR-110 Buzzer 110VAC/DCBZRL-110 Buzzer with Red LED 110VAC/DCBZR-230AC Buzzer 230ACBZRL-230AC Buzzer with Red LED 230ACMax. Recommended Load (10,000 Ops)Part No. Countdown RangeLED Lamp 2-8WFilament LampFlourescent LampSST-5-1C 30sec. - 20min. 70W 2300W 230WMax. Recommended Load (10,000 Ops)Part No. No. of Switching SegmentsLED Lamp 2-8WFilament LampFlourescent LampSMT-96-1C 96 x 15mins. 100W 2600W 170WMax. Recommended Load (10,000 Ops)Part No. No. of ON/ OFF ProgramsLED Lamp 2-8WFilament LampFlourescent LampSDT-20-1C 20 100W 2600W 650WSDTC-20-1C 20 100W 2600W 650WSDT-58-2C 58 100W 2600W 650WSDTA-58-2C 58 100W 2600W 650WPart No. No. of WaysRated CurrentRated Voltage (UL / IEC)Dimensions (h x w x d)SLC-2W 2 32A 300V / 450V 20.5 x 12.8 x 14.52mmSLC-3W 3 32A 300V / 450V 20.5 x 17.4 x 14.52mmSLC-5W 3 32A 300V / 450V 20.5 x 26.6 x 14.52mmPart No. No. of WaysRated CurrentRated Voltage (UL / IEC)Dimensions (h x w x d)SPC-2W 2 32A 600V / 450V 19.7 x 13.6 x 10.1mmSPC-3W 3 32A 600V / 450V 19.7 x 19.2 x 10.1mmSPC-5W 5 32A 600V / 450V 19.7 x 30.4 x 10.1mmPart No. No. of TerminalsBody TypeCurrent Carrying at 450VWire CapacitySWCA3 3 Straight 25A 0.5 - 4mm2SWCA5 5 Straight 16A 0.5 - 2.5mm2SWCT3 3 %u201cT%u201d Type 16A 0.5 - 2.5mm2SWCT5 5 %u201cT%u201d Type 16A 0.5 - 2.5mm2Part No. Cable RangeSCG/M12-* 3 - 6.5mmSCG/M16-* 5 - 10mmSCG/M20-* 6 - 12mmSCG/M20L-* 10 - 14mmSCG/M25-* 9 - 16mmSCG/M25L-* 13 - 18mmSCG/M32-* 18 - 25mmSCG/M40-* 22 - 32mmSCG/M50L-* 30 - 38mmSCG/M63-* 34 - 44mmAvailable ColoursWHITE WBLACKBGREY GRED RAvailable ColoursWHITE GREEN BLUERED ORANGEPart No. DescriptionSTDK1 Copy key for use with STDC-20-1CPart No. Voltage RatingPLGT-12-* 12VAC/DCPLGT-24-* 24VAC/DCPLGT-110-* 110VAC/DCPLGT-230AC-* 230ACTo order Stag IP68 Cable Glands, please replace the %u201c*%u201d shown in the order code with the colour letter as indicated above.Eg. SCG/M20L-RTo order Stag IP67 LED Pilot Lights, please replace the %u201c*%u201d shown in the order code with the colour letter as indicated above.Eg. PLGT-12-ORANGEimo stagScrewless Lever ConnectorsIP68 Waterproof ConnectorsCurrent Wire CapacityPA66 connectors in straight or %u201cT%u201d typeBody Type Carrying at Current Intermittent buzzers with optional red LED
