337SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEIP65 Pushbuttons Ø22.5mmIP65 Indicators Ø22.5mmModular Heating & Lighting ContactorsIP66 Enclosed IsolatorsChangeover Output RelaysOverloads for Contactors or StartersSockets for RelaysIP66 Large Body IsolatorsDIN Rail MountableMulti-Function TimerDIN RailIP65 Enclosed Direct On-line StartersIP65 Pushbutton EnclosuresPushbutton Contact BlocksPart No. DescriptionPB01C Black PushbuttonPB02C Green PushbuttonPB03C Red PushbuttonPB04C 2 Position Rotary Knob 120°PB05C 3 Position Rotary Knob 60°PB06C Panel Accessory Kit Panel Collarwith 1 NO + 1 NC Contact BlockPB07C E-Stop Button Pull to Release 40mmPB08C E-Stop Button Key Release 40mmPB09C Red Mushroom Stop Button(non-latching) 40mmPB10C 2 Position Key Switch 60°PB11C 3 Position Key Switch 60°PB13C E-Stop Button Twist to Release40mm “O” MarkingPB14C Complete E-Stop Station Pull toRelease 1NO + 1NCPB15C Complete E-Stop Station Twist toRelease 1NO + 1NCPB17C Complete Palm/Foot E-Stop StationTwist to Release 2NCPB19C E-stop ShroudPB20C Emergency Stop Disc LabelPart No. DescriptionPL04C Red Pilot Light 230VACPL05C Green Pilot Light 230VACPL06C Red Pilot Light 24VAC/DCPL07C Green Pilot Light 24VAC/DCPart No. DescriptionCR40C Contactor 20A 2 Pole 240VACCR46C Contactor 25A 2 Pole 240VACCR41C Contactor 25A 4 Pole 240VACCR44C Contactor 40A 2 Pole 240VACCR45C Contactor 63A 2 Pole 240VACCR42C Contactor 40A 4 Pole 240VACCR43C Contactor 63A 4 Pole 240VACPart No. DescriptionIS01C 20A 3 Pole inc. 4x M20 GlandsIS02C 20A 4 Pole inc. 4x M20 GlandsIS03C 25A 3 Pole inc. 4x M20 GlandsIS04C 25A 4 Pole inc. 4x M20 GlandsIS11C 32A 3 Pole inc. 4x M20 GlandsIS12C 32A 4 Pole inc. 4x M20 GlandsIS05C 40A 3 Pole inc. 4x M25 GlandsIS06C 40A 4 Pole inc. 4x M25 GlandsPart No. DescriptionRL01C 2 Pole 10A 8 Pin 240VAC RelayRL02C 3 Pole 10A 11 Pin 240VAC RelayRL05C 2 Pole 10A 8 Pin 24VAC RelayRL06C 2 Pole 10A 8 Pin 24VDC RelayRL07C 3 Pole 10A 11 Pin 24VAC RelayRL08C 3 Pole 10A 11 Pin 24VDC RelayRL09C 2 Pole 10A 8 Pin 12VDC RelayRL11C 4 Pole 5A 14 Pin 240VAC RelayRL12C 4 Pole 5 A 14 Pin 24VDC RelayPart No. DOL Rating Star/Delta RatingOL03D 1.2A-1.8A -OL04D 1.8A-2.7A -OL05D 2.7A-4.0A -OL06D 4.0A-6.0A 7.0A-10.5AOL07D 6.0A-9.0A 10.5A-15.5AOL08D 8.0A-11.0A 14.0A-19.0AOL09D 10.0A-14.0A 18.0A-24.0AOL10D 13.0A-18.0A 23.0A-31.0APart No. DescriptionBA01C 8 Pin Base for DPCO RelayBA02C 11 Pin Base for 3PCO RelayBA03C 14 Pin Base for 4PCO RelayPart No. DescriptionIS02CL 20A 4 Pole inc. 4x M20 GlandsIS12CL 32A 4 Pole inc. 4x M20 GlandsIS06CL 40A 4 Pole inc. 4x M25 GlandsPart No. DescriptionTM34C 1 Pole CO 10A Relay Output 24-250VAC/DCPart No. DescriptionDR01C 1m Galvanised Slotted DIN RailPart No. DescriptionSR01D 4kW DOL Starter 240VAC CoilSR02D 4kW DOL Starter 415VAC CoilSR03D 7.5kW DOL Starter 240VAC CoilSR04D 7.5kW DOL Starter 415VAC CoilPart No. DescriptionEN01C Single Button EnclosureEN02C Single Button Enclosure Yellow CoverEN03C Double Button EnclosureEN04C Triple Button EnclosurePart No. DescriptionCT01C Contact Block 1NO + 1NCCT02C Contact Block 2NOCT03C Contact Block 2NCMotor Control Gear
