P. 335

                    SWITCHGEAR & DISTRIBUTION Distribution Boards
Switch Fuses
Heavy duty fuse products for use in commercial and industrial environments, providing isolation and traditional fuse protection for electrical loads.
iKQ RCBO’s
• Manufactured and tested to BS EN 61009 10kA breaking capacity
• Let through energy classification of 3 (lowest let through energy best cable protection classification)
• Positive contact indication. (guaranteed on/off indication) Trip free MCB mechanism
• Automatic trip on loss of neutral
• Automatic protection against reverse
polarity Type C tripping characteristics (5ln to
10ln) 6 - 45A; 10, 30 & 100mA sensitivities
• AC class sensitivity
• For use in LoadCentre A and B boards
• One single pole way occupied in a distribution
board Cable capacity 16mm2
• Speed of connection of plug on devices
• Assured system integrity, no other devices fit
KQ boards
   Twinbreak
Heavy duty fuse products for use in commercial and industrial environments, providing isolation and traditional fuse protection for electrical loads.
• Rated for 240/415V 50/60Hz.
• Ratings 20A, 32A, 63A, 100A, SP&SwN, TP&N.
• Utilisation category AC20A, AC21A, AC22A,
AC23B at rated current.
• Degree of protection IP41.
• Handle position provides positive contact
indication.
• Door handle prevents door being opened when
switch is ON or padlocked.
• Handle padlockable in ON and OFF positions.
• Fuse links supplied as standard.
Twinbreak Switch Disconnectors
Quadbreak
Heavy duty fuse products for use in commercial and industrial environments, providing isolation and traditional fuse protection for electrical loads.
• Rated for 240/415V 50/60Hz.
• Ratings 100A, 160A, 200A, 250A, 315A, 400A,
500A, 630A TP&N.
• Utilisation category AC20A, AC21A, AC22A,
AC23B at rated current, AC23A for ratings up
to 160A.
• Handle position provides positive
contact indication.
• Door handle prevents door being opened when
switch is ON or padlocked.
• Handle padlockable in ON and OFF positions.
• Device may be fed to either top or
bottom terminals.
• Fuse links or copper links supplied
as standard.
Quadbreak Switch Disconnectors
Twinbreak Switch Fuses
  Part No. SPSN Part No. TPN Rating
  SD202SW
 SD203SW
 20A
 SD322SW
  SD323SW
  32A
 SD632SW
SD633SW
63A
 SD1002SW
 SD1003SW
 100A
 -
  SD1253SW
  125A
 -
 SD1603SW
 160A
  Part No. SPSN Part No. TPN Rating
  SD202SFK
 SD203SFK
 20A
 SD322SFK
  SD323SFK
  32A
 SD632SFK
 SD633SFK
 63A
 SD1002SFK
 SD1003SFK
 100A
  Code Sensivity 10mA
Code Sensivity 30mA
Code Sensivity 100mA
Rating
 SEE106C01
 SEE106C03
 SEE106C10
 6A 10kA
 SEE110C01
 SEE110C03
 SEE110C10
 10A 10kA
 SEE116C01
  SEE116C03
  SEE116C10
  16A 10kA
 SEE120C01
SEE120C03
SEE120C10
20A 10kA
 SEE125C01
 SEE125C03
 SEE125C10
 25A 10kA
 SEE132C01
 SEE132C03
 SEE132C10
 32A 10kA
 SEE140C01
  SEE140C03
  SEE140C10
  40A 10kA
 SEE145C01
 SEE145C03
 SEE145C10
 45A 10kA
         Code SPSN
Code TPN
Recom- mended Cable Entry Box
iKQ Residual Current Devices
(RCDs)
All residual current circuit breakers are suitable for use as main incomers in LoadCentre KQ distribution boards.
• Comply with BS EN 61008.
Specification for residual current operated circuit breakers
• Rated voltage 240/415V AC 50/60 Hz
• Test button enables RCCB to be tested periodically
  Part No. DP Part No. FP Rating
  SED25032
  SED25034
  25A 30mA
 -
SED25104
25A 100mA
 SED25302
 SED25304
 25A 300mA
 SED40032
 SED40034
 40A 30mA
 SED40102
  SED40104
  40A 100mA
 SED40302
SED40304
40A 300mA
 SED63032
  SED63034
  63A 30mA
 SED63102
SED63104
63A 100mA
 SED63302
 SED63304
 63A 300mA
 SED80032
 SED80034
 80A 30mA
 SED100032
  -
  100A 30mA
 SED1001102
 -
 100A 100mA
 -
 SED100304S
 100A 300mA TD
  Quadbreak Switch Fuses
 Code SPSN
Code TPN
Recom- mended Cable Entry Box
Rating
 SQB0632L
 SQB0633L
 SQBX100
 63A
 SQB1002L
  SQB1003L
  SQBX100
  100A
 SQB1602L
SQB1603L
SQBX160
160A
 SQB2502L
 SQB2503L
 SQBX250
 250A
 -
 SQB4003L
 SQBX500
 400A
 -
  SQB5003L
  SQBX500
  500A
 -
 SQB6303L
 SQBX630
 630A
 -
 SQB8003L
 SQBX630
 800A
           SQBX100
  SQB1602K
SQB1603K
SQBX160
SQBX250
160A
    SQB2002K
SQB2003K
200A
    SQB2502K
SQB2503K
SQBX250
250A
    -
-
SQB3153K
SQBX500
315A
    SQB4003K
SQBX500
400A
    -
-
SQB5003K
SQB6303K
SQBX500
500A
    SQBX630
630A
     Together we
335
