P. 334

                    SWITCHGEAR & DISTRIBUTION Distribution Boards
Distribution Boards
• Manufactured and tested to BS EN 60439-3 Maximum busbar rating 125A
• External IP3X protection to BS EN 60529
• IP2XB finger safe with door and cover removed
to BS EN 60529, provided by permanent, non
removable, factory fitted barriers
• Fully shielded neutral bars
• Earth and Neutral bar capacity 25mm2
• All incoming connections are the same length
i.e. 4 pole configuration
• Range of integral incomers for all applications
including lugs, switches and RCDs
LoadCentre iKQ Single Phase Type A 125A Distribution Boards
Incomers not included.
Miniature Circuit Breakers
     • Outgoing MCBs available up to 63A B, C or D curves 18mm wide RCBOs available, minimising use of outgoing ways
• Plug-on outgoers for speed of installation and reliable connection
• All B boards accept DIN control products (timers, contactors) in any unused outgoing way without adaptation Control wiring cable way integrated to moulding
LoadCentre iKQ Three Phase Type B 250A Distribution Boards
Incomers not included.
Loadcentre iKQ 250A Incoming Devices
Incoming device supplied separately to distribution board.
Loadcentre iKQ Type B Miniature
Circuit Breakers
• Manufactured and tested to BS EN 60898
• 10kA breaking capacity
• Let through energy classification of 3
(lowest let through energy giving best cable
protection classification)
• Positive contact indication
(guaranteed on/off indication)
• Trip free mechanism operates even when the
toggle is locked on
• Lockable in the ON or OFF position
• Speed of connection of Plug-On devices -
guaranteed connection Plug-On devices
• For use in LoadCentre KQ A and B boards
      Part No. Rating
 SE10B106
 6A 10kA
 SE10B110
10A 10kA
 SE10B116
 16A 10kA
 SE10B120
  20A 10kA
 SE10B132
32A 10kA
 SE10B140
 40A 10kA
 SE10B150
  50A 10kA
 SE10B163
 63A 10kA
  Part No.
Modules
24 Modules
Dimensions H x W x D (mm)
Part No.
Modules
Dimensions H x W x D (mm)
 SE125A6
 6 Modules
 270 x 266 x 127
 SE125A8
  8 Modules
  270 x 321 x127
 SE125A12
12 Modules
270 x 376 x127
 SE125A16
  16 Modules
  270 x 456 x127
 SE125A24
 24 Modules
 500 x 376 x127
         SE12B250
4 Modules
754 x470 x139
   SE18B250
6 Modules
754 x470 x139
   SE24B250
8 Modules
808 x470 x139
1240 x470 x139
Loadcentre iKQ Type C Miniature Circuit Breakers
   SE36B250
12 Modules
  SE48B250
16 Modules
970 x470 x139
 1078 x470 x139
   SE54B250
18 Modules
1078 x470 x139
Part No. SP Part No. TP Rating
  SE10C106
  SE10C306
  6A 10kA
 SE10C110
SE10C310
10A 10kA
 SE10C116
 SE10C316
 16A 10kA
 SE10C120
 SE10C320
 20A 10kA
 SE10C125
  SE10C325
  25A 10kA
 SE10C132
SE10C332
32A 10kA
 SE10C140
 SE10C340
 40A 10kA
 SE10C150
  SE10C350
  50A 10kA
 SE10C163
 SE10C363
 63A 10kA
  Loadcentre iKQ 125A Incoming Devices
Incoming device supplied separately to distribution board.
LoadCentre iKQ Type B Metering Kit
Kit comprising of an extension box to be fitted to the LoadCentre KQ distribution board.
Kit supplied fully fitted and wired. Components included in the kit are A9MEM3255 Multi-function meter provides V.A, Power factor kW/h, kYA/h & three current transformers.
Loadcentre iKQ Type D Miniature Circuit Breakers
   SE72B250
     Part No. Description Rating
  SE125L2
 DP Terminal Block
 125A
 SE125SW2
 DP Switch Disconnector
 125A
 SED63032
 DP RCD
 63A 30mA
 SED63102
  DP RCD
  63A 30mA
 SED63302
DP RCD
63A 30mA
 SED100032
  DP RCD
  100A 30mA
 SED100102
 DP RCD
 100A 30mA
  Part No. Description Rating
     SE250L4P
FP Terminal Block
250A
   SE160SW3L
TPN Switch Disconnector
160A
   SE200SW3L
TPN Switch Disconnector
200A
   SE250SW3L
TPN Switch Disconnector
250A
   SE160SW4
FP Switch Disconnector
160A
   SE200SW4
 SE250SW4
FP Switch Disconnector
FP Switch Disconnector
200A
  250A
Part No. TP Rating
 SE10D310
 10A 10kA
 SE10D316
 16A 10kA
 SE10D320
20A 10kA
 SE10D332
 32A 10kA
 SE10D340
 40A 10kA
 SE10D350
  50A 10kA
 SE10D363
 63A 10kA
     SE100MC- CB3L
TPN MCCB
100A
   SE160MC- CB3L
TPN MCCB
160A
   SE200MC- CB3L
TPN MCCB
200A
   SE250MC- CB3L
TPN MCCB
250A
Part No. Description
   SE250MET Multi-function Metering Kit
    SE160RCD
FP RCD
160A 30mA
    334
