P. 328

                    SWITCHGEAR & DISTRIBUTION Circuit Protection
RCBOs 30mA Un-Switched Neutral
Compact RCBOs 30mA Switched Neutral
       Part No.
B Trip Curve
Rated Current
Class
 Part No.
B Trip Curve
Rated Current
Class
 RCBO-B06/30/SPA
 6
 A
 RCBO-B10/30/SPA
 10
 A
 RCBO-B16/30/SPA
 16
 A
 RCBO-B20/30/SPA
  20
  A
 RCBO-B32/30/SPA
 32
 A
 RCBO-B40/30/SPA
 40
 A
     RCBO-06/30/SPA
  RCBO-10/30/SPA
Also available in C Trip Curve
Single Phase SPDs
6
10
A
 A
   RCBO-16/30/SPA
16
A
   RCBO-20/30/SPA
20
A
   RCBO-32/30/SPA
32
A
   RCBO-40/30/SPA
40
50
A
   RCBO-50/30/SPA
A
Also available in C Trip Curve
      Part No.
Voltage Protection Level (Up)
Nominal Discharge Current (In) (8/20μS)
Max. Continous Operating Voltage (Uc)
Configuration
Response Time
Total Modules
  SRG2TCU
  <1.5kV
  20kA (L/N) (L/PE) 40Ka (N/PE)
  275 VAC
  1+1 (Connection Type CT2)
  <20nS
  1
    Surge Protection Kit
Electricity Isolator Switch
        Part No.
Enclosure Modules
Main Switch
Dimension Drawing
 SLM2-MS
  2
  100A DP
  SLM2
 SLM4-MS
 4
 100A DP
 SLM4
   Part No. Description
       SRG1VCU-KIT SRGT2CU + 40MCB + Cable Set for Lewden Consummer Units
  328
