P. 322

                    SWITCHGEAR & DISTRIBUTION
Fuses
Street Lighting Fuse-Links
230/240 Volt Street Lighting Fuse-Links to IEC 60269-I/BS 88-1.
Rated Voltages 240V A.C. Breaking Capacity 20kA. Breaking Range and Utilisation Category gG
• Lawson Type ‘LST’ fuse-links are for use in single-phase street lighting cut-outs or similar installations
• These fuse-links comply with UK Electricity Supply Industry Standards and BS7654
• Leading authorities including Lloyds Register of Shipping and Electricity Supply Authorities, have approved fuse-links within this range
lawson fuses limited
      Part No.
Current Rating (A)
Fixing Centre
 (mm)
  (ins)
  LST2
 2
38
11⁄2
 LST4
 4
 38
 11⁄2
 LST6
 6
 38
 11⁄2
 LST10
  10
  38
  11⁄2
 LST16
16
38
11⁄2
 LST20
 20
 38
 11⁄2
 LST25
  25
  38
  11⁄2
 LST32
 32
 38
 11⁄2
   Plug Top Fuse-Links
230/240 Plug Top Fuse-Links to IEC 60269-3/BS 88-3 and BS 1362 Rated Voltage 240V A.C. Breaking Capacity 6kA AC
• Lawson Type PL Fuse-Links are intended primarily for use in UK domestic plugs to BS 1363, but may also be installed in appropriate single phase installations with fault levels up to 6kA
• With a BS1362 plug top fuse-link, the flexible cable connected to domestic equipment can always be fully protected against the effects of overload or small over currents when correctly fused
• BS1362 colour coding PL 1, 2 and 7 are also available, details on request
     Part No.
Current Rating
Colour Coding
Dimensions
 Preferred
 Other
 Preferred
 Other
 L (mm)
 L (ins)
 D (mm)
 D (ins)
 PL1
 -
 1
 -
 Black
 25.4
 1
 6.3
 1⁄4
 PL2
  -
  2
  -
  Black
  25.4
  1
  6.3
  1⁄4
 PL3
3
-
Red
-
25.4
1
6.3
1⁄4
 PL5
 -
 5
 -
 Black
 25.4
 1
 6.3
 1⁄4
 PL7
 -
 7
 -
 Black
 25.4
 1
 6.3
 1⁄4
 PL10
  -
  10
  -
  Black
  25.4
  1
  6.3
  1⁄4
 PL13
 13
 -
 Brown
 -
 25.4
 1
 6.3
 1⁄4
