                    SWITCHGEAR & DISTRIBUTION Fuses
Electricity Supply Fuse-Links with Wedge Connections
400/415 Volt Electricity Supply Distribution Fuse-Links to IEC 60269-2/BS 88-2
Rated Voltage 41 SV A.C. Breaking Capacity 80kA A.C. Breaking Range and Utilisation Category gU
• Lawson Type “J” fuse-links are for use in a.c. electricity supply networks. They are installed in distribution boards, feeder pillars, link boxes, pole mounted cut-outs and heavy duty ser vice intakes
• The range includes all the current ratings specified in 8S88-2 and BS 7656 for fuse-links with the standard 82mm and 92mm fixing centres, together with additional non-standardised fuse-links with 76mm fixing centres and female contact fuse-links
• In addition, a range of cylindrical fuse-links up to 315 Amps, with the same characteristics as the tagged pattern, is available for installation in pole mounted cut-outs
     Current Rating (A)
Fixing Centres G
Cylindrical LxD 47x40mm
 76mm (3”)
  82mm (3 1/4”)
  92mm (3 5/8”)
  20
JHU 20
JPU 20
JSU 20
 JF 20
 32
 JHU 32
 JPU 32
 JSU 32
 JF 32
 40
 JHU 40
 JPU 40
 JSU 40
 JF 40
 50
  JHU 50
  JPU 50
  JSU 50
  JF 50
 63
JHU 63
JPU 63
JSU 63
JF 63
 80
 JHU 80
 JPU 80
 JSU 80
 JF 80
 100
 JHU 100
 JPU 100
 JSU 100
 JF 100
 125
 JHU 125
 JPU 125
 JSU 125
 JF 125
 160
  JHU 160
  JPU 160
  JSU 160
  JF 160
 200
JHU 200
JPU 200
JSU 200
JF 200
 250
 JHU 250
 JPU 250
 JSU 250
 JF 250
 315
 JHU 315
 JPU 315
 JSU 315
 JF 315
 355
  -
  JPU 355
  JSU 355
  -
 400
-
JPU 400
JSU 400
-
 450
 -
 JPU 450
 JSU 450
 -
 500
  -
  JPU 500
  JSU 500
  -
 560
-
JPU 560
JSU 560
-
 630
  -
  JPU 630
  JSU 630
  -
 800
 -
 -
 JSU 800
 -
