                    SWITCHGEAR & DISTRIBUTION Fuses
Consumer Unit Fuse-Links
230/240 Consumer Unit Fuse-Links to IEC 60269-3/BS 88-3 and BS 1361
Rated Voltage 240V a.c. Breaking Capacity 16.SkA a.c. Breaking Range and Utilisation Category gG
• Lawson type L Fuse-Links are for use in household consumer units or other single phase installations with fault levels up to 16.SkA
• They can be fitted into Pullcap Fuse-Holders or other suitable Fuse-Holders
Note: In addition to the current ratings specified in BS 1361, additional ratings certified to BS 88 have been included to meet other requirements.
    Part No.
Current Rating
BS 1361 Colour Coding
Principal Dimensions
 (A) BS 1361
  (A) BS 88
  L (mm)
  L (ins)
  D (mm)
  D (ins)
  LA2
-
2
 -
23
7/8
6.35
1/4
 LA5
 5
 -
 White
 23
 7/8
 6.35
 1/4
 LC2
 -
 2
 -
 26
 1
 10.32
 13/32
 LC5
 -
 5
 -
 26
 1
 10.32
 13/32
 LC8
  -
  8
  -
  26
  1
  10.32
  13/32
 LC10
-
10
-
26
1
10.32
13/32
 LC15
 15
 16
 Blue
 26
 1
 10.32
 13/32
 LC20
 20
 20
 Yellow
 26
 1
 10.32
 13/32
 LD6
  -
  6
  -
  29
  1 1/8
  12.7
  1/2
 LD10
-
10
-
29
1 1/8
12.7
1/2
 LD16
 -
 16
 -
 29
 1 1/8
 12.7
 1/2
 LD20
 -
 20
 -
 29
 1 1/8
 12.7
 1/2
 LD25
  -
  25
  -
  29
  1 1/8
  12.7
  1/2
 LD30/32
30
32
Red
29
1 1/8
12.7
1/2
 LK35
 -
 35
 -
 35
 1 3/4
 16.67
 1/32
 LK40
  -
  40
  -
  35
  1 3/4
  16.67
  1/32
 LK45
 -
 45
 Green
 35
 1 3/4
 16.67
 1/32
