SWITCHGEAR & DISTRIBUTION Circuit Protection
Metal Consumer Units
Populated MCB
100A DP Fused Switch
Part No.
MS Rating
Total Ways
Main Switch
RCCBs (30mA)
MCBs (B Type)
PRO-PM10 100A 10 1 2 x 63A 2 x 6A, 1 x 16A, 3 x 32A
Part No. Description Dimensions (mm)
FS6380100
100A Fused Switch (Metal / AC21) inc. 63A, 80A & 100A Fuses (22x58 IEC 60269-2) gG
250 x 135 x 87
Main Switch
Garage Boards
Part No.
MS Rating
Total Ways
Main Switch
RCCBs (30mA)
MCBs (B Type)
PRO-MCGARAGE-63
-
2
-
1 x 63A
1 x 6A, 1 x 16A
PRO-MCGARAGE-MS
100A
2
1
-
1 x 6A, 1 x 16A
Part No. MS Rating Total Ways
PRO-MX04M
100A
2
PRO-MX08M
100A
6
PRO-MX10M
100A
8
PRO-MX12M
100A
10
PRO-MX16M
100A
14
PRO-MX21M
100A
19
Miniature Circuit Breakers Single Pole
Switch Disconnectors Range
Part No.
B Trip Curve
Rated Current
G06-1B06
6
G06-1B10
10
G06-1B16
16
G06-1B20
20
G06-1B32
32
G06-1B40
40
G06-1B50
50
Part No. Description
MSF Main Switch Fused including 80A ME Type Fuse
Also available in C Trip Curve
